Summary of Contents for Vessel GT-3800PX
-
Page 2: For Safe Use
For Safe Use Thank you very much for having purchased the "VESSEL Air Impact Wrench GT-3800PX." Please be sure to carefully read this manual before use and fully understand the contents for the safe and correct use of the air tool. - Page 3 For Safe Use ■The work environment for the air tool. Warning ●Use tools at an appropriate air pressure. Since using more than the specified air pressure may cause damage to the product and accidents, set the pressure gauge and reduction valve, etc., and use tools at an appropriate air pressure (Air pressure by hand).
- Page 4 For Safe Use a hat or take other measures to prevent entanglement in tools. ●Wear protective gear. Wear protective gear suitable for work including a helmet, protective goggles, earplugs, dust mask, gloves insulated against vibration and safety shoes, etc. ■ Warning Using the Air Tool ●Avoid abusing by damaging, dropping or hitting.
-
Page 5: Warning ■Others
For Safe Use and request a maintenance inspection and repairs. Warning ■Others ●Do not use the tool except for the specified application. Be sure to never use the tool for work other than the specified application as it could lead to accidents. ●Never modify the tool. - Page 6 For Safe Use directly in the eyes or ears. ●Handle the air tool carefully. Since handling the tool roughly could lead to accidents or malfunction of the tool, do not jar the air tool by throwing or dropping it. ●Handle the air hose carefully. Do not use the air hose to hold or to raise and lower the air tool.
- Page 7 For Safe Use ●Conduct maintenance and inspections. To work safely and efficiently do not neglect maintenance or inspections. ●Contact our company or a service factory (assigned) approved by our company for repairs. Contact our company or a service factory (assigned) approved by our company for repairs through the store or agency etc.
-
Page 8: How To Use The Tool
How to use the tool ・For handling and operation, be sure to follow the procedures in the instruction manual. ・The following uses are prohibited. * When the sockets or bits are incorrectly installed nor fit properly in size. *When the work stance is unstable or when the tool is not properly held and cannot be operated. - Page 9 How to use the tool connected hoses. ●Turning the tool on for the first time following purchase When first installing this device after purchase or when changing the hoses, blow out any dirt in pipes and hose before installation. Also, it is necessary to idle the device for a few seconds because oil in this tool is expelled with the exhaust.
- Page 10 How to use the tool How to use the tool ●Starting and stopping １．Connecting the air coupling. ２．Supply air with the compressor. ３．When the start lever is pulled or pushed, the function starts. ４．When the start lever is released (disengaged), the function stops.
- Page 11 How to use the tool * Start the product after confirming the rotation direction. * When work is discontinued or finished, be sure to turn off the air. * Do not point the exhaust towards people or fire. The exhaust is dangerous since it contains oil.
-
Page 12: Maintenance / Repairs
Maintenance / Repairs ・ We recommend periodic inspections for safe, worry free use. If inspections are neglected, it may affect the performance, lifespan and safety of the product. ・ Inspection (maintenance) should be conducted only by those who carefully read and fully understood the instruction manual for this product. - Page 13 Maintenance / Repairs ●Start lever … Return condition Confirm whether the lever returns correctly. It is very dangerous to use the tool continuously in the situation where the lever does not return correctly because the tool will start suddenly after connected. If the lever does not correctly return, please request repairs.
-
Page 14: Troubleshooting
Troubleshooting Air tool troubleshooting Symptom Cause Remedies Air is not provided. Turn on the air. The hose is twisted. Straighten the hose. Air pressure is low. Adjust the air pressure. Parts are rusted due to a Lubricate/disassemble and 1. No rotation lack of lubrication. - Page 15 Troubleshooting Trouble with the valve (O-ring damage, ball rust, 7. Air is leaking. Replace parts. or worn-out, damaged and rusted springs) etc. Bolts came loose. Install new parts. Worn out and damaged Replace parts. bearings. Damage to the hammer Replace parts. case and impact part.
- Page 16 Capacity（Bolt Dia.） 39mm Working Torque Range 353-1607Nm Weight 8.9kg Overall Length 269.5mm Free Load 4100rpm Working Air Pressure 0.6Mpa 0.7 ㎥/min Air Consumption Air Compressor 3.75kw or bigger Air Hose Inner Dia. 12.7mm Accessories VESSEL Air Coupling（BPB-4） “L” Wrench（A/F 5mm） Description...
- Page 17 Exploded diagram drawing & Parts list...
-
Page 18: Parts List
Exploded diagram drawing & Parts list Parts List Number Required Index No Description Size per unit １ Hammer Housing Complete VB40525 （Installed No. 1） <2> Oil Seal （Installed No. 1） <3> Pressed In Bushing Washer, Spring Hex Cap Bolt M8×37 １... - Page 19 Exploded diagram drawing & Parts list Number Required Index No. Description Size per Unit １ Valve, Throttle １ Spring, Throttle １ Handle Cap １ Screw, Handle Cap Retainer M4x 12 Pan Screw, Cross Hollow Inlet Bushing Case, Silencer １ O-Ring, Silencer Case Parts with <...
- Page 20 GT-3800PX MODEL SERIAL NO. Manufactured by: 17-25, Fukae-Kita 2-chome, Higashinari-ku, Osaka 537-0001 Japan Tel : +81 6 6976 7778 Fax : +81 6 6972 9441 E-mail : export@vessel.co.jp URL : http://www.vessel.jp 20061220...
