- Page 1 USER’S GUIDE LSI60800 PCI to USB Host Adapter Version 1.1 N o v e m b e r 2 0 0 0 ® S14000.A...
-
Page 2: Electromagnetic Compatibility Notices
Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic. -
Page 3: What Is Covered In This Guide
1 What is Covered in This Guide This User’s Guide provides instructions and illustrations to help you install a LSI Logic LSI60800 PCI to USB Host Adapter. It covers the following topics: Ensuring USB support is available in Windows 98... -
Page 4: Hardware Installation
Figure 1 External USB Cable 2 Hardware Installation Before you begin the board installation, switch off the power to the computer and any peripheral devices and disconnect all power cords. Important: 1. Remove the cover on your computer to access the PCI slots. Refer to your computer documentation if necessary. - Page 5 4. Remove the LSI60800 Board from the antistatic bag and insert the edge connector into the PCI slot, as pictured in Figure 2. Make sure the edge connector is properly aligned before pressing the board into place. Apply even pressure to both ends of the board while inserting it. 5.
-
Page 6: Verifying The Installation
A sequence of windows will appear briefly one after the other. First the New Hardware Found window will appear. Then the next window will indicate that the LSI Logic LSI61C102 USB Host Controller is the device that was found. Then a window will indicate that the Controller is an unknown device. - Page 7 Figure 3 5. Click on Close. 4 Connect the USB Devices 1. Load the USB device driver supplied by the USB device manufacturer following the procedure provided with the USB device. 2. Plug in the USB device using the correct cable (see below). There is no need to turn off the computer power.
- Page 8 4.1 Cabling The LSI60800 PCI to USB Host Adapter supports type A cable connectors only. The USB specification provides for two types of cables. For full-speed devices like scanners, cameras, printers, and speakers, a full-speed cable must be used. For low-speed devices like keyboards, mice, joysticks, and other game devices, a sub-channel or low-speed cable can be used.
- Page 9 Notes LSI60800 PCI to USB Host Adapter...
- Page 10 LSI Logic; nor does the purchase, lease, or use of a product or service from LSI Logic convey a license...
