USER'S
GUIDE
PCI-X to 3.0 Gbit/s
Serial Attached SCSI
(SAS) Host Adapters
Model Numbers:
LSISAS3041X, LSISAS3041XL
LSISAS3442X, LSISAS3442XL
LSISAS3080X, LSISAS3080XL
LSISAS3800X
LSISAS3801X, LSISAS3801XL
J u n e 2 0 0 6
Version 2.1
®
DB15-000333-02
