- Page 1 5100 Automatic Battery Scrubber Model No.s: Operator Manual 611363 611634 611555 Rev. 00 (02 01) Home Find... Go To..
-
Page 2: Table Of Contents
Install. Date - The machine is operated with reasonable care. Serial No.- The machine is maintained regularly - per the machine maintenance instructions provided. E2001 Tennant Company The machine is maintained with manufacturer supplied or equivalent parts. TABLE OF CONTENTS SAFETY PRECAUTIONS . -
Page 3: Safety Precautions
ENGLISH 5. When servicing machine: SAFETY PRECAUTIONS – Avoid moving parts. Do not wear loose jackets, shirts, or sleeves. – Block machine tires before jacking This machine is intended for commercial use. It is machine up. designed to scrub hard floors in an indoor environment –... -
Page 4: Machine Components
ENGLISH MACHINE COMPONENTS 1. Key Switch 14. Wand Kit ON/OFF Switch (Opt.) 28. Brush Trigger 2. Power ON/OFF Indicator Light 15. ES ON/OFF Switch (ESt Model) 29. Recovery Tank Lid 3. Hour Meter (Opt.) 16. Pump On Light (ESt Model) 30. -
Page 5: Machine Installation
ENGLISH Battery Specifications: Two 12 volt, deep cycle batteries. Consult with an MACHINE INSTALLATION Authorized Distributor for specific batteries. Maximum battery dimensions are 17.8cm(7 in) W x 33cm(13 in) L x 25.4cm(10 in) H. UNCRATING MACHINE 1. Park machine on a level surface and turn off all switches and remove key. -
Page 6: Machine Setup
ENGLISH 6. Connect black battery cable coming from machine to negative (–) post of top battery. Then connect MACHINE SETUP opposite end of black jumper cable to positive (+) post (Figure 4). (–) Jumper Black ATTACHING SQUEEGEE ASSEMBLY Cable Cable 1. -
Page 7: Installing Pad Driver Or Brush
ENGLISH 5. Place pad driver or brush on floor in front of machine. While tilting the machine backwards, INSTALLING PAD DRIVER OR BRUSH center the scrub head down over the pad driver 1. Raise scrub head to transport position. Step down (Figure 13). -
Page 8: Removing Pad Driver Or Brush
ENGLISH 4. Fill solution tank with 28L (7.5 gal) of clean water using a hose as shown. (60°C/140°F maximum REMOVING PAD DRIVER OR BRUSH temperature). To fill with bucket, use a bucket with 1. Raise scrub head to transport position. Step down a spout firmly on scrub head lift pedal to raise (Figure 16). -
Page 9: Adjusting Control Handle Height
ENGLISH ADJUSTING CONTROL HANDLE HEIGHT SCRUBBING WITH MACHINE The control handle has three height settings to 1. Release brush lift pedal from transport position by stepping down on scrub head release pedal accommodate a comfortable operating height. (Figure 21). 1. Locate two control handle height adjustments knobs on handle (Figure 20). -
Page 10: Operating Est Model
ENGLISH 4. Pull brush triggers and begin walking with 2. Turn on ESt switch. During operation the ESt machine. The brush will propel the machine pump will automatically start recycling when ESt forward allowing little effort maneuvering the pump on light turns on (Figure 26). -
Page 11: Circuit Breakers
ENGLISH ATTENTION: Do not continue to operate machine when battery meter is in the red zone, battery ADJUSTING SOLUTION FLOW damage will result. To increase or decrease the maximum solution flow, 10. On last scrubbing pass, turn off solution switch turn adjustment knob. -
Page 12: Adjusting Squeegee Lift Cable
ENGLISH ADJUSTING SQUEEGEE LIFT CABLE To adjust squeegee lift cable, loosen lock nuts and turn adjustment stem on squeegee cable. Retighten lock nuts after adjusting (Figure 30). FIG. 31 NOTE: If using a bucket to drain machine, do not use same bucket for filling, or be certain to rinse it out before refilling machine. -
Page 13: Battery Charging
ENGLISH 5. Plug charger’s DC output connector to battery connector located at rear of machine BATTERY CHARGING (Figure 34). The following charging instructions are intended for the 24V charger supplied with the machine. Only use a charger with the following specifications to prevent battery damage. -
Page 14: Machine Maintenance
ENGLISH WEEKLY MAINTENANCE MACHINE MAINTENANCE (Every 20 Hours of Operation) 1. Flush out tanks and solution lines. Pour 750 ml. To keep machine in good working condition, simply (24 oz.) of an acetic acid solution with 11.3 ltr. (3 follow the daily, weekly and monthly maintenance gal.) of hot water into solution tank. -
Page 15: Transporting Machine
ENGLISH BATTERY MAINTENANCE TRANSPORTING MACHINE WARNING: Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and When transporting machine by use of trailer or truck, open flame away. Keep battery compartment open be certain to follow tie–down procedures below: when charging. -
Page 16: Trouble Shooting
ENGLISH TROUBLE SHOOTING PROBLEM CAUSE SOLUTION No power, nothing runs. Faulty key switch. Contact Service Center. Batteries need charging. See CHARGING BATTERIES. Faulty battery(s). Replace battery(s). Loose battery cable. Tighten loose cable. MAIN circuit breaker has tripped. Determine cause and reset circuit breaker button. -
Page 17: Specifications
Loose vacuum motor. Contact Service Center. Battery charge level is low. Charge batteries. Do not run machine when battery meter is in the red zone. SPECIFICATIONS MODEL Tennant 5100 LENGTH 99cm (39 in) WIDTH 49.5cm (19.5 in) HEIGHT 91cm (36 in) WEIGHT 71kg (158lbs.), with batteries 131kg (290lbs.)
