Meter Description

1. LCD display
2. Channel 2 value, unit and function
3. Channel 1 value, unit and function
4. ZERO function
5. Frequency function
6. Record function
7. Manual range key
8. Shift key
9. Max/Min/Hold key
10. Channel 1/Channel 2 select key
11. Rotary function selection switch
for Channel 2
12. Rotary function selection switch
for Channel 1
13. Common input jack
14. Channel 1 V/mV/Ω/Cap/Diode/TTL
input jack
15. Channel 2 V/mV/mA/µA input jack
16. 10A input jack
2
3
7
8
11
15
16
4
1
4
5
6
9
10
12
13
14
