Summary of Contents for Maxx Cold MCR27U
- Page 1 Undercounter Refrigerator Manual Undercounter Refrigerator Manual...
- Page 2 ▣ Model – MCR27U 1. Technical Specifications 115V 3.2A Connection 15 amp plug Name R134a Refrigerant Q'ty (oz) Q'ty (gram) 1/5 HP Compressor Samsung SD162C L1U2 SD162C-L1U2 2. Function Specifications Temp Range ℉ 32℉ ~ 40℉ Capacity Capacity Cubic Feet...
- Page 3 ▣ Model – MCR36U 1. Technical Specifications 115V 3.2A Connection 15 amp plug Name R134 R134a Refrigerant Q'ty (oz) Q'ty (gram) 1/5 HP Compressor Compressor Samsung Samsung SD162C-L1U2 SD162C L1U2 2. Function Specifications Temp Range ℉ 32℉ ~ 40℉ Capacity Cubic Feet Climate Class Max Ambient Temp...
- Page 4 ▣ Model – MCR48U 1. Technical Specifications 115V 6.0A Connection 15 amp plug Name R134a Refrigerant Q'ty (oz) Q'ty (gram) 3/8 HP Compressor Compressor Samsung Samsung SK1A1C L2W SK1A1C-L2W 2. Function Specifications Temp Range ℉ 32℉ ~ 40℉ Capacity Capacity Cubic Feet Cubic Feet Climate Class...
- Page 5 ▣ Model – MCR60U 1. Technical Specifications 115V 6.0A Connection 15 amp plug Name R134a Refrigerant Q'ty (oz) Q'ty (gram) 3/8 HP Compressor Compressor Samsung Samsung SK1A1C L2W SK1A1C-L2W 2. Function Specifications Temp Range ℉ 32℉ ~ 40℉ Capacity Capac y Cubic Feet Cub c ee Climate Class...
- Page 6 ▣ Model – MCR72U 1. Technical Specifications 115V 6.1A Connection 15 amp plug Name R134a Refrigerant Q'ty (oz) Q'ty (gram) 3/8 HP Compressor Compressor Samsung Samsung SK1A1C L2W SK1A1C-L2W 2. Function Specifications Temp Range ℉ 32℉ ~ 40℉ Capacity Capacity Cubic Feet Cubic Feet Climate Class...
- Page 7 ▣ Cabinet - 1 Stainless BOLT – M5 HINGE BOTTOM(LEFT) HINGE BOTTOM(RIGHT) HINGE TOP ASSEMBLY...
-
Page 8: Door Gasket
▣ DOOR HINGE SHAFT DOOR GASKET SPRING LEFT SPRING RIGHT... - Page 9 ▣ Cabinet - 2 Louver Duct Evaporator Fan Motor Kit REF-Thermostat Kit Shelf Pilaster Evaporator Shelf Clip Shelf Clip Hinge Bottom Shelf...
- Page 10 ▣ Machine room (Refrigeration)-1 Back Panel Back Panel...
- Page 11 ▣ Machine room (Refrigeration)-2 Condensing Unit Disassembly – MCR27U / 36U / 48U / 60U / 72U CAPILLARY Dryer SUCTION PIPE Condenser Compressor Unit Base Hot Pipe Condenser fan motor Assembly Condenser fan motor - Assembly Evaporating pan (dish)
- Page 12 ▣Compressor Wiring – SD162C-L1U [MCR27U, MCR36U] Overload Protector 4TM427PHBYY-53 PTC R l PTC Relay - J531Q33E100M200-2 Running Capacitor 250VAC-12㎌...
- Page 13 ▣ Compressor Wiring – SK1A1C-L2W [MCR48U, MCR60U, MCR72U] Overload Protector 4TM795TFBZZ-53 PTC R l PTC Relay - J531Q34E220M350-3 Running Capacitor 250VAC-12㎌ Starting Capacitor 125VAC-125㎌...
-
Page 14: Wiring Diagram
▣ Wiring Diagram [MCR27U, MCR36U] HARNESS COMP Compressor Type [SD162C-L1U] HARNESS MAIN POWER CORD... - Page 15 ▣ Wiring Diagram [MCR48U, MCR60U, MCR72U] Ref.3Dr/72Model HARNESS COMP Compressor Type [[SK1A1C-L1U2] HARNESS MAIN POWER CORD...
