- Page 1 MCR3U INSTRUCTION MANUAL Indoor Refrigerator Be sure unit is standing upright 24 hours prior to plug-in. English MCR3UMAN 0511 REV B PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS Read all instructions before using this appliance. Use this appliance only for its in- tended purpose as described in this instruction manual. Always exercise basic safety precautions, as described below. After reading the instruction manual, store it in an accessible place where the user(s) of this product can easily find it. - Page 3 IMPORTANT SAFEGUARDS 1. All repairs, disassembly and modifications should be performed only by qualified technicians. Attempting to perform these yourself could result in fire, malfunction or in- jury. 2. Never splash water directly onto the product or wash it with water without unplug- ging, as a short circuit could result.
- Page 4 1. This unit must be properly installed in accordance with the installation instructions before it is used. See grounding instructions in the Installation section. 2. This model can either be built-in or free-standing. Built-in units vent at the bottom front and airflow at the front of this vent must be unimpeded. 3.
-
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS Model Number: MCR3U Description: Indoor Refrigerator Electrical Input: 115VAC ~ 60Hz Current Rating: 2.0A Unit Dimensions: 14⅝”W x 24 ”D x 33½”H 371.475 mm W x 619.125 mm D x 850.9 mm H Unit Weight: 69 lbs/31.29kg Ambient Temperature Range: 25ºF - 100ºF /3.8ºC -37.77ºC... -
Page 6: Installation
INSTALLATION Remove the exterior and interior packaging. Use a soft dry cloth to wipe down the outside of the refrigerator thoroughly. Use a clean cloth dampened with lukewarm water to wipe down the inside of the refrigerator. Air must circulate freely in front of the refrigerator. Avoid placing the appliance near any source of heat or moisture, or in direct sunlight. - Page 7 INSTALLATION door. Set aside. 5. Using a Phillips screwdriver, remove the magnet baffle and door switch baffle, then place them on the opposite side at the top of the door. 6. Push the four plug buttons into the spare screw holes. To replace door on hinges: 1.
-
Page 8: Operating Your Refrigerator
OPERATING YOUR REFRIGERATOR IMPORTANT: Do not plug in the refrigerator for 24 hours after unit is set in place. Failure to do so may result in the unit working improperly. This refrigerator has a rotary temperature control knob (thermostat) inside the unit which is marked with the settings OFF-COLD-COLDEST in order of increasing coldness. - Page 9 OPERATING YOUR REFRIGERATOR variation from the bottom of the unit to the top. The temperature at the bottom of the unit will always be slightly colder. Operating the Internal Light This appliance has an internal light to make it easier for you to see the foods you have stored.
-
Page 10: Cleaning And Maintenance
CLEANING & MAINTENANCE Cleaning the Outside Unplug your refrigerator. Clean the outside with a cloth dampened in warm soapy water. Dry thoroughly with a soft cloth. To clean the door gasket, use only warm soapy water. Never use harsh cleansers or scouring pads to clean any part of your unit. -
Page 11: Troubleshooting
TROUBLESHOOTING Unit does not turn on Not plugged in. Fuse blown or circuit breaker tripped. Noise or vibration Check that unit is level. If not, adjust leveling legs. Unit is too warm Check that door is properly closed and sealed. Check temperature setting. -
Page 12: Wiring Diagram
WIRING DIAGRAM... - Page 13 NOTES:...
- Page 14 NOTES:...
- Page 15 NOTES:...
- Page 16 www.maxxcold.com 3355 Enterprise Ave, Suite #160, Fort Lauderdale, FL 33331 Phone:(954) 202-7419 · Fax:(954) 202-7337...
