PROEL M1622USB User Manual

16-ch 4-bus mixer with fx and usb
Hide thumbs Also See for M1622USB:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

See also: User Manual
M1622USB
16-CH 4-BUS MIXER
WITH FX AND USB
USER MANUAL
MANUALE D'USO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M1622USB and is the answer not in the manual?

Questions and answers

Related Manuals for PROEL M1622USB

Summary of Contents for PROEL M1622USB

  • Page 1 M1622USB 16-CH 4-BUS MIXER WITH FX AND USB USER MANUAL MANUALE D'USO...

  • Page 2: Fcc Compliance Notice

    PROEL. PROEL reserves the right to make any aesthe c, func onal or design modifi ca on to any of its products without any prior no ce.

  • Page 3: Table Of Contents

    INDEX INDICE FCC COMPLIANCE NOTICE ....2 SPECIFICHE TECNICHE ..... . 4 TECHNICAL SPECIFICATIONS .

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE MODEL M1622USB Connectors MODELLO M1622USB Conne ori MONO INPUT CHANNELS CANALI INGRESSO MONO Mic Input Sensi vity from 0 to -60 dBu Sensibilità Ingresso Mic da 0 a -60 dBu Balanced XLR-F XLR-F Bilanciato Mic Input Impedance...

  • Page 5: Mechanical Dimensions

    MECHANICAL DIMENSIONS DIMENSIONI MECCANICHE 46.5 cm 18.3" 43.7 cm 17.2"...

  • Page 6: Layout

    LAYOUT LAY-OUT...

  • Page 7: Control Panel (Fig.1)

    CONTROL PANEL (FIG.1) PANNELLO DI CONTROLLO (FIG.1) 61 62...

  • Page 8: Control Panel (Fig.2)

    CONTROL PANEL (FIG.2) PANNELLO DI CONTROLLO (FIG.2) CONNECTIONS CONNESSIONI p - hot p - hot ring - cold cold ground sleeve - ground LINE IN, various OUT LINE IN, OUT vari LINE IN, various OUT LINE IN, OUT vari Jack (balanced) Jack (bilanciato) Jack (unbalanced) Jack (sbilanciato)

  • Page 9: Configuration Example

    DIBOX FLASH12HDA ac ve processed speaker or other AUDIO SYSTEM PERSONAL COMPUTER WITH USB 2.0 PORT HEADPHONES external sound processor normally open temporary pedals (proel: GF29) FLASH5A desktop monitors WD12A wedge monitor or other AUDIO SYSTEM or other stage monitors...

  • Page 10: English Language

    This warranty does not extend to damage resul ng from improper installa on, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is s ll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any "direct damage"...

  • Page 11: General Information

    19” rack moun ng. M1622USB, off ering 16 inputs and 12 microphone channels, has been fi ed not only with one more AUX send and with the USB rou ng, but also with an easy-to-use COMPRESSOR sec on on each MONO channel.
  • Page 12 7. EQ sec on HIGH control This control gives you up to 15dB boost or cut at 12KHz with a “SHELVING” curve shape. Use it to increase or reduce the sound “clarity” or “brightness”. 8. EQ sec on MID control This control gives you up to 15 dB boost or cut at the frequency determined by the FREQ knob (see FREQ next) with a "PEAKING"...
  • Page 13 channel. The solo signal is post-fader if SOLO MODE is in AFL posi on, so what you check is the signal sent from the channel fader to the MAIN MIX. 22. FADER LEVEL control It adjusts the level of the channel signal and sends it to the MAIN MIX and/or to the GROUPS 1-2 buses. 23.
  • Page 14 ¼” (6.3mm) unbalanced (TS) jack for temporary, normally open footswitch (not supplied - suggested footswitch is the PROEL model GF29). When “TAP DELAY” eff ects (p 9, 10, 15) are selected, by pressing at least two mes the footswitch it’s possible to set the desired delay me, according to music rhythm.
  • Page 15 NOTE: the MAIN OUT is a true balanced output that can send the signal on a balanced line with or without a phantom power ac ve. So the M1622USB mixer can also be used as a combina on mixer + DI box for sending the signals to a...
  • Page 16 M1622USB as a high-quality soundcard for recording and playback with Windows and Macintosh computers. VERY IMPORTANT INFORMATIONS: - The M1622USB internal USB soundcard needs a personal computer with a USB 2.0 port and a Windows (XP or later) or Mac OSX (10.3 or later) Opera ng Systems.
  • Page 17 STEREO JACK connector for the headphones output: only stereo headphones with a minimum impedance of 32 Ohms should be connected to this output. 81. LAMP 12V / 0.5A socket This BNC connector provides +12V power supply for gooseneck lamps. Use only lamps with MAX 5W power consump on. PROEL suggested types are SDC670 or SDC670LED.
  • Page 18 82. +48V phantom switch and LED This switch ac vates (LED on) and deac vates (LED off ) the phantom power on MIC Inputs. Most professional condenser microphones require phantom power, which is a lower DC voltage delivered to the microphone on pin 2 and 3 of the XLR microphone connector.

  • Page 19: Lingua Italiana

    • I Prodo Proel sono des na esclusivamente ad un u lizzo specifi co di po sonoro: segnali di ingresso di po audio (20Hz-20kHz). Proel declina ogni responsabilità per danni a terzi causa da mancata manutenzione, manomissioni, uso improprio o installazione non eseguita secondo le norme di sicurezza.

  • Page 20: Informazioni Generali

    19”. Il nuovo mixer M1622USB, dispone di 16 ingressi di cui 12 microfonici come il modello precedente, include una mandata AUX in più e una fl essibile ges one del segnale USB del computer e dotato inoltre di un COMPRESSORE per ogni ingresso MONO.
  • Page 21 manifestarsi fenomeni di feedback. 7. EQ HI (equalizzatore controllo al ) Questo controllo perme e di guadagnare o a enuare fi no a 15dB a 12KHz con una curva di po “SHELVING”. Da usarsi per aumentare o ridurre la “chiarezza” o “brillanza” del suono. 8.
  • Page 22 canale. Il segnale SOLO è post-fader se SOLO MODE è in posizione AFL, quindi si tra a del segnale inviato dal canale al MAIN MIX. 22. FADER LEVEL (controllo di livello del canale) Regola il livello del segnale del canale e lo invia ai bus MAIN MIX e/o GROUPS 1-2. 23.
  • Page 23 ¼” (6.3mm) jack sbilanciato (TS) per un pedale footswitch con conta o temporaneo normalmente aperto (non fornito - un pedale suggerito è il modello PROEL GF29). Quando un eff e o “TAP DELAY” è selezionato (p 9, 10, 15), premendo almeno due volte il pedale è...
  • Page 24 39. FX MUTE (ingresso jack per pedale) Conne ere un pedale footswitch per silenziare (MUTE) l’eff e o interno del mixer (un pedale suggerito è il modello PROEL GF29). 40. MIX / 1-2 (tasto assegnazione FX) Questo interru ore assegna il segnale di uscita dell'eff e o interno FX al bus MAIN MIX (se è sollevato) o al bus GROUPS 1-2 (se è...
  • Page 25 Windows e Macintosh. INFORMAZIONI IMPORTANTI: - La scheda sonora interna al mixer M1622USB richiede un computer munito di una porta USB 2.0 e un sistema opera vo Windows (XP o successivi) o Mac OSX (10.3 o successivi).
  • Page 26 68. EQ IN / BYPASS (tasto disa vazione equalizzatore grafi co) Premendo questo tasto si disa va l'equalizzatore grafi co STEREO a 7 bande, sia che venga usato sulle uscite MIX o sulle mandate AUX. 69. MIX L / AUX 1 (EQ grafi co a MIX L o a AUX 1) Premendo questo tasto si assegna il canale LEFT dell'equalizzatore STEREO a 7 bande al MIX LEFT (tasto sollevato) oppure ad AUX 1 (tasto premuto).
  • Page 27 81. LAMP 12V / 0.5A (presa per lampada fl essibile) Questo conne ore BNC fornisce l'alimentazione a +12V per una lampada fl essibile. Usare esclusivamente lampade con 5W di potenza massima. PROEL suggerisce i modelli SDC670 o SDC670LED. 82. +48V interru ore alimentazione phantom Questo interru ore a va e disa va l’alimentazione phantom negli ingressi microfonici MIC.
  • Page 28 PROEL S.p.A. (World Headquarter) Via alla Ruenia 37/43 64027 Sant’Omero (TE) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.proel.com REV. 51/12 CODE 96MAN0064...
