Interface
Console
LAN (P1 ~ P4)
WAN/DMZ (P1 ~ P4)
FXS
FXO
ISDN S0/TE
ISDN ALL TE
Factory Reset button
PWR
ON/OFF
:
Vigor3300V+ Series Quick Start Guide
Description
Provided for technician use.
Connecter for local networked devices.
Connecter for remote networked devices.
Connecter for telephone set.
Connecter for FXS interface of PABX or PSTN line.
Connecter for ISDN phone/ISDN line.
Connecter for ISDN line.
Used to restore the default settings. Turn on the router
(ACT LED is blinking). Press the hole and keep for more
than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the router
will restart with the factory default configuration.
Connecter for a power cord.s
Power switch.
