- Page 1 Issue 1 Description: ROBINHOOD ISLAND CANOPY 90CM Model Numbers: RIE3CL9SS Product may vary slightly from the picture...
-
Page 2: Pre-Installation
Pre-installation Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control and every rangehood is tested and approved before it leaves the factory Important: Please read the entire instructions before installing the rangehood, always switch power off prior to installation. - Page 3 Pre-installation •The canopy hood is designed for 2400mm (8ft) and 3000 (10ft) ceilings. •The chimney is telescopic and is designed for hood installations between 650 to 750mm above the cooking surface* •Ascertain the desired installation height of the canopy hood* •Any installation above 750mm will compromise the extraction performance.
-
Page 4: Contents Of Packaging
Extra lengths and/or bends may be required, depending on the length required and whether there is any structural material in the way, e.g. rafters. Please note that this chart is designed as a guide. Please consult Robinhood customer services if unsure. -
Page 5: Installation
Installation Before drilling any holes check that the area behind the surface to be drilled is clear of any electrical cables, pipes etc. The ceiling must take a weight bearing of at least 40kgs weight. Whenever possible protect the Rangehood with a fabric sheet or similar. 1. - Page 6 Installation...
- Page 7 Installation...
-
Page 8: Control Panel
Certificate). Description Part number code 2620 Charcoal Filter RIE (3 per pack) Chimney Extension 10' Set RIE3CL9SS includes: - 1pc 10ft Ext Chimney Top 1000mm 2205 - 1pc 10ft Ext Top Chimney Install Brackets 1000mm - 1pc Chimney Bottom 600mm... -
Page 9: Important Safety Information
Product approvals and ratings Product approval number TUV15730/1EA Product rating 220-240V, 50Hz, Total Power 277W, motor265W, Lamp 4 x 3W, Class I Electrical approval AS/NZS 60335.2.31:2004 + A1 + A2 + A3 EMC AS/NZS CISPR14:2001 Performance tested IEC61591 Important safety information The canopy hood is not intended for use by persons (including children) with reduced physical, sensory or metal capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person... - Page 10 5. To make a claim under this warranty, you must produce the original invoice or other purchase documentation as proof of the original purchase date. You must send your claim to Robinhood Australia Pty Limited, 17 Oasis Court, Clontarf QLD 4019 within 7 days of any alleged defect or failure of the product first becoming apparent, you are responsible for the expense of making a claim under this warranty.
- Page 11 The product was not used, cleaned or cared for in accordance with our instructions. The product was used outdoors. All Robinhood rangehoods are suitable for indoor use only, and not suitable over BBQs or charcoal cookers designed for outdoor use.
