Installation - Zephyr Napoli ZNA-M90CS Use, Care And Installation Manual

MODELS: ZNA-M90CS, ZNA-E42CS
PARTS SUPPLIED
(2) Top Duct Covers
(2) Bottom Duct Covers
(1) Hood Body
(1) Hardware package
HARDWARE PACKAGE CONTENTS
(3) Wire Nuts
(4) M6 x 1"
wood srews
(4) 3/16 x 1/4" pan-head
machine screws
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Duct cover extension accessory
- Recirculating kit accessory
(1) 8" round damper (pre-installed)
(4) 3W LED Light Bulbs
A
(2) Baffle Filters
(8) M4 x 8
(4) ø12 OD / ø5
ID Washers
(1) M4 x 12
safety screw
4
www.zephyronline.com
(1) Top Support Frame
(1) Bottom Support Frame
Front of Hood
C L
B
Cut-Out Shaded Area
(1) Paper ceiling template
