1
IR Receiver
2
POWER Switch
3
OFF Button
4
INPUT SELECTOR Buttons
5
PANEL LOCK Button
6
INPUT HDMI Connectors
7
RS-232 9-pin D-sub Port
8
ETHERNET Connector
9
RESET Button
10
OUTPUT HDMI Connector
11
Power Connector with Fuse
1 First, disconnect the power cord and then connect it again while pressing the RESET button. The unit powers up and loads
its memory with the factory default definitions
Your VS-81H 8x1 Switcher
Table 1: VS-81H 8x1 HDMI Switcher Features
Feature
The red LED lights when receiving signals from the
Infrared remote control transmitter
Illuminated switch for turning the unit ON or OFF
Press to toggle disconnecting the output
Blinks when the EDID of the connected monitor is
different from the last EDID that was saved
Press the INPUT button to select input (from 1 to 8)
Press to toggle disengaging the front panel buttons, to
acquire the EDID and to set to the PC/DVD mode
Connect to the HDMI sources (from 1 to 8)
Connects to the PC or the RS-232 Remote Controller
Connects to the PC or other Ethernet Controller
Press the ETHERNET factory reset button to reset to the
factory default definitions
IP number − 192.168.1.39
Mask – 255.255.255.0
Gateway – 192.168.1.1
Connect to the HDMI acceptor
AC connector enabling power supply to the unit
Function
1
:
7
