Page 1: User Manual
K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: VS-81HDxl 8x1 HD/SD‑SDI Switcher P/N: 2900-000418 Rev 4... -
Page 3: Table Of Contents
Protocol 2000 Syntax Instruction Codes Figures Figure 1: VS-81HDxl 8x1 HD/SD‑SDI Switcher Front Panel Figure 2: VS-81HDxl 8x1 HD/SD‑SDI Switcher Rear Panel Figure 3: Connecting the VS-81HDxl 8x1 HD/SD‑SDI Switcher Figure 4: VS-81HDxl MACHINE ID DIP-switches Figure 5: Crossed Cable RS-232 Connection... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Achieving the Best Performance To achieve the best performance: Use only good quality connection cables (we recommend Kramer high- performance, high-resolution cables) to avoid interference, deterioration in signal quality due to poor matching, and elevated noise levels (often associated with low quality cables) ... -
Page 6: Safety Instructions
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/. -
Page 7: Overview
Overview The Kramer VS-81HDxl is a true 8x1 switcher for SD/HD/3G HD-SDI signals that lets you switch any one of the eight inputs to two identical outputs. The VS-81HDxl features: A maximum data rate of 3Gbps HDTV compatibility ... -
Page 8: Defining The Vs-81Hdxl 8X1 Hd/Sd-Sdi Switcher
The VS-81HDxl can be controlled via the: Front panel buttons Infrared remote control transmitter Infrared remote extension cable transmitter Remotely, by RS-232 or RS-485 serial commands transmitted by a touch screen system, PC, or other serial controller ... -
Page 9: Figure 1: Vs-81Hdxl 8X1 Hd/Sd-Sdi Switcher Front Panel
Figure 1: VS-81HDxl 8x1 HD/SD‑SDI Switcher Front Panel Feature Function IR Receiver The red LED is illuminated when receiving signals from the infrared remote control transmitter POWER Switch Illuminated switch for turning the unit ON or OFF OFF Button Press to disconnect the outputs... -
Page 10: Figure 2: Vs-81Hdxl 8X1 Hd/Sd-Sdi Switcher Rear Panel
Figure 2: VS-81HDxl 8x1 HD/SD‑SDI Switcher Rear Panel Feature Function GENLOCK IN BNC Connector Connect to the genlock source GENLOCK TERM Button Press to terminate the genlock source (75) or release for looping to another unit GENLOCK LOOP BNC Connector... -
Page 11: Using The Ir Transmitter
This distance can be extended to up to 60m (200ft) when used with three extension cables (Model: C-A35M/A35F-50). Before using the external IR receiver, be sure to arrange for your Kramer dealer to insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm connector that fits into the REMOTE IR opening on the rear panel. -
Page 12: Installing In A Rack
Installing in a Rack This section provides instructions for rack mounting the unit. VS-81HDxl - Installing in a Rack... -
Page 13: Connecting The Vs-81Hdxl
VS-81HDxl. After connecting your VS-81HDxl, connect its power and then switch on the power to each device. You can use your VS-81HDxl to switch one of the eight HD/SD SDI inputs to the two identical HD/SD SDI outputs, as the example illustrated in Figure 3 shows. -
Page 14: Dip-Switch Settings
Section 5 6. If required, connect a remote contact closure switch (see .5). 7. Connect the power cord. Figure 3: Connecting the VS-81HDxl 8x1 HD/SD‑SDI Switcher DIP-Switch Settings By default, all the DIP-switches are set to OFF. Figure 4... -
Page 15: Connecting To The Vs-81Hdxl Via Rs-232
The MACHINE ID determines the position of a VS-81HDxl unit, specifying which VS-81HDxl unit is being controlled when several VS-81HDxl units connect to a PC or serial controller. Set the Machine number on a VS-81HDxl unit via MACHINE ID DIPs 1, 2, 3 and 4, according to the following table. -
Page 16: Connecting A Pc Or Controller To The Rs-485 Port
Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter Connecting a PC or Controller to the RS-485 Port You can operate the VS-81HDxl via the RS-485 port from a distance of up to 1200m (3900ft) using any device equipped with an RS-485 port (for example, a PC). -
Page 17: Switching Genlocked Video Signals
When turning the machine ON, the appropriate button will flash to indicate the latest setup (last setup is saved). Operating via Ethernet You can connect to the VS-81HDxl via Ethernet using either of the following methods: Section 5 Directly to the PC using a crossover cable (see .5.1) - Page 18 5.5.1 Connecting the Ethernet Port Directly to a PC You can connect the Ethernet port of the VS-81HDxl directly to the Ethernet port on your PC using a crossover cable with RJ-45 connectors. This type of connection is recommended for identifying the VS-81HDxl with the factory configured default IP address.
-
Page 19: Figure 7: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4 (TCP/IPv4) depending on the requirements of your IT system. 5. Click Properties. The Internet Protocol Properties window relevant to your IT system appears as shown in Figure 8 Figure VS-81HDxl - Connecting the VS-81HDxl... -
Page 20: Figure 8: Internet Protocol Version 4 Properties Window
Figure 8: Internet Protocol Version 4 Properties Window Figure 9: Internet Protocol Version 6 Properties Window VS-81HDxl - Connecting the VS-81HDxl... -
Page 21: Figure 10: Internet Protocol Properties Window
8. Click Close. 5.5.2 Connecting the Ethernet Port via a Network Hub or Switch You can connect the Ethernet port of the VS-81HDxl to the Ethernet port on a network hub or using a straight-through cable with RJ-45 connectors. 5.5.3... -
Page 22: Controlling Via The Remote Connector
DO NOT connect more than one PIN to the GND PIN at the same time. For example, to route input 5 to the outputs, as the example in Figure 11 illustrates, momentarily touch input # 5 to the GND (ground) pin. Figure 11: Using the REMOTE Connector VS-81HDxl - Connecting the VS-81HDxl... -
Page 23: Operating The Vs-81Hdxl
Locking the Front Panel To prevent changing the settings accidentally or tampering with the unit via the front panel buttons, lock your VS-81HDxl. Unlocking releases the protection mechanism. Nevertheless, even though the front panel is locked you can still operate via RS-232 or RS-485, as well as via the Kramer IR Remote Control Transmitter. -
Page 24: Technical Specifications
19” x 7” x 1U (W, D, H) rack mountable DIMENSIONS: WEIGHT: 1.5kg (3.3lbs) approx. INCLUDED ACCESSORIES: Power cord, null-modem adapter, external remote IR receiver cable P/N: C-A35M/IRR-50 Specifications are subject to change without notice at http://www.kramerelectronics.com VS-81HDxl - Technical Specifications... -
Page 25: Protocol 2000
OVR bit is set, then all machine numbers accept (implement) the command and the addressed machine replies. When a single machine is controlled over the serial port, always set M4…M0 to 1, and make sure that the machine itself is configured as MACHINE NUMBER = 1. VS-81HDxl - Protocol 2000... -
Page 26: Instruction Codes
OUTPUT is assigned the value of the requested parameter. The replies to instructions 10 and 11 are according to the definitions in instructions 7 and 8 respectively. For example, if the present status of machine number 5 is breakaway setting, then the reply to HEX code: is HEX code: VS-81HDxl - Protocol 2000... - Page 27 NOTE 25 – For units that detect the validity of the video inputs, instruction 16 is sent whenever the unit detects a change in the state of an input (in real-time). For example, if input 3 is detected as invalid, the unit sends HEX code: If input 7 is detected as valid, then the unit sends HEX code: VS-81HDxl - Protocol 2000...
- Page 29 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
