MIXING VALVE ADJUSTMENT:
For customers who wish to adjust the flavor of the drink, the mixing valve changes the water to
concentrate ratio. This valve is very sensitive. Only slight rotation of the mixing rod is needed
to change the ratio (1/16th to 1/8th of a turn). The standard setup, as the unit comes from the
factory, is approximately 7:1 ratio, which will give you a 5 to 8 percent brix based on the sweet
tea concentrate.
1. To adjust the valve, tilt the dispenser on it's side.
2. Look underneath the unit and locate the adjusting rod.
3. Turn counter-clockwise for stronger drink – turn clockwise for weaker drink. Taste the tea
with each adjustment to determine the desired consistency.
CAUTION – Do not rotate adjusting rod more than 2 full turns from closed position. More turns will cause the
adjustment rod to disengage from the mixing valve, with a resulting leak.
WARNING DO NOT
refrigerate unused
tea overnight for later
consumption.
CLEANING
STRAINER CLEAN-OUT
1. Turn off the water flow running from the facility to the strainer.
2. Use pliers to grab the housing of the strainer and with an adjustable wrench, remove the cap.
3. Take out the wire strainer and clean out the contents. Use a spiral bristled brush to clean inside the strainer.
4. Rinse the strainer and replace it into the housing.
5. Return the cap to the housing and turn on the water line.
DAILY CLEANING
Regular cleaning of the TCCN tea dispenser is essential in maintaining the highest quality iced tea your equipment is
capable of producing. Prepare a mild cleaning solution of dish washing detergent and warm water.
1. Wipe any spills, dust or debris from the exterior surfaces, with a damp cloth. Apply a stainless steel polish to
prevent scratches.
2. Turn off water supply at valve behind unit.
3. Open the dispensing faucet to relieve pressure in the dispensing lines.
4. Remove the top cover and clean with the cleaning solution.
5. Clean the faucet assembly.
a. Remove the handle/seat cup assembly from the faucet by holding the bonnet and unscrewing.
b. Clean the faucet cap and silicone seat cup assembly.
c. Use a spiral brush soaked in cleaning solution to clean inside the faucet body.
d. Run the brush through the adapter on the body of the dispenser.
6. Rinse and dry parts that were removed. Assemble the dry parts onto the unit.
TEA TIPS
1. Never hold finished dispensed tea for more than eight hours at room temperature.
Discard any unused tea after eight hours
2. Dispense only enough tea that you reasonably expect to sell within a few hours.
3. To protect tea flavor and to avoid bacterial contamination and growth, clean and
sanitize tea brewing, storage and dispensing equipment at least once a day.
3
