Input Connectors of the MEA2100-System from Contact Unit to Headstage
(100-Pin Fischer Connectors 50 mil)
Connector on the left side, when looking to the front of the MEA2100 headstage
without contact unit and with the articulation of the headstage in the back.
Pin 1 and 2
Pin 3 to 30
Pin 31 to 34
Pin 35 to 38
Pin 39 to 98
Pin 99 and 100
Connector on the right side, when looking to the front of the MEA2100 headstage
without contact unit and with the articulation of the headstage in the back.
Pin 1 and 2
Pin 3 and 62
Pin 63 to 66
Pin 67 to 70
Pin 71 to 98
Pin 99 and 100
GND (Ground)
not connected
internal coding
GND (Ground)
Channel 1 to 60
GND (Ground)
GND (Ground)
Channel 61 to 120
GND (Ground)
internal coding
not connected
GND (Ground)
Appendix
