4
Hardware
4.1 Hardware Configuration
The MEA2100-System is a flexible system, which can be used in different configurations. At the
moment five types of headstages are available for the MEA2100-System, which can be connected
to the interface board once or twice: A headstage for one MEA with 32 (MEA2100-HS32), with 60
(MEA2100-HS60), or with 120 electrodes (MEA2100-HS120). Respectively headstages for two MEAs
are available, for two MEAs with 32 or 60 electrodes each (MEA2100-HS2x32 or MEA2100-HS2x60).
One or two headstages can be connected to the interface board of the MEA2100-System.
MEA2100-HS2x60
Two MEA2100-HS2x60
Two MEA2100-HS120
27
