MultiChannel MEA2100-System User Manual page 57

Integrated Stimulus Generators
Output current
Current output compliance voltage
Output voltage
Voltage output compliance current
Stimulation pattern
Number of stimulation channels
Resolution
Interface Board
Dimensions (W x D x H)
Weight
Front panel
4 Digital inputs
4 Digital outputs
2 Auxiliary channels (not in use)
Rear panel
1 16 bit Digital In / Out
1 20-pin connector: Analog IN Channel
3 to 8, additionally pins used for DSP
2 Analog Inputs, Channel 1 and
Channel 2
2 USB high speed ports
Power Supply
Ground
1 Audio Output
+/- 1.5 mA
+/- 10 V
+/- 12 V
+/- 20 mA
rectangle: biphasic, monophasic, pulse trains
3 independent stimulation patterns
per 60 channels
16 bit
250 mm x 83 mm x 25 mm
300 g
Lemo connector, EPL.00.250 NTN
Lemo connector, EPL.00.250 NTN
Lemo connector, EPL.00.250 NTN
68-pin MCS standard connectors
20-pin connector (2,54 mm grid),
dual row standard IDC
Lemo connector, EPL.00.250 NTN
USB 2.0 high speed cable
(type A - mini B, 5 Pin)
MPU 30, scope of delivery,
PWR DC 0.65 x 2.75 mm
Common jack 4 mm, banana plug
Stereo jack 3.5 mm, FFA.00.250 CTAC29
Appendix
53
