Eurotherm 2216L Installing And Operating Instructions

2216L and 2208L
Installing and Operating Instructions
The 2216L and 2208L are precision PID temperature controllers
ideal for plastic extrusion machines, ovens, chillers and other
heating and cooling processes. The 2216L is in a 48 x 48mm panel
size (1/16 DIN) and the 2208L in a 48 x 96 panel size (1/8 DIN).
Both controllers have up to three outputs for heating, cooling and
alarms. In addition the 2208L has two contact closure inputs to
select second setpoint and standby mode (all outputs off, except
alarms).
D I
IMENSIONS AND NSTALLATION
Model 2216L
48mm (1.89in)
2216
OP1
48mm
OP2
SP2
(1.89in)
REM
RUN
MAN HOLD
Model 2208L
48mm (1.89in)
2208
OP1 OP2
DD DD
96mm
DD DD
(3.78in)
SP2 REM
E C
LECTRICAL ONNECTIONS
1A +
Heating
or Logic
Output
1B -
+
2A
Cooling
or Logic
Output
-
2B
3A
Alarm
Output
3B
Model 2216L
Output ratings
Relay: 2A, 264Vac resistive
Logic: 18Vdc, 20mA (non-isolated)
Alarm output
The alarm output is non-latching and
de-energised in the alarm state
Grounding
The ground connection is not
required for safety purposes but must
be connected to satisfy EMC
requirements
Temperature Controllers
103mm (4.01in)
Panel cut-out
45 x 45mm
1.77 x 1.77in
Panel retaining clips
103mm (4.01in)
92 x 45mm
+0.8
3.62 x 1.77in
+0.03
L
Line
85-264Vac
N
Neutral
Ground
VI
Sensor +
V+
input
T/C
Pt100
V-
-
Wire Sizes
All electrical connections are made to the
screw terminals at the
controller. These accept wire sizes from
2
0.5 to 1.5 mm (16 to 22 AWG), and are
protected by a hinged cover to prevent
hands or metal making accidental contact
with live wires. Rear terminal screws
should be tightened to a torque of 0.4 Nm
(3.5 lb in).
.
The controller will have been built and configured according to
the ordering code given on page 5. Check the ordering code on
the controller side labels to determine the configuration of your
particular controller.
This controller meets the European directives on safety
and EMC.
To install the controller
Please read the safety information on pages 5 & 6 before
proceeding.
Prepare the panel cut-out to the size shown
Insert the controller through the cut-out.
Spring the panel retaining clips into place. Secure the
-0.0 +0.6
controller in position by holding it level and pushing both
retaining clips forward.
-0.00 +0.02
Unplugging the controller
The controller can be unplugged from its sleeve by easing the
latching ears outwards and pulling it forward out of the sleeve.
When plugging the controller back into its sleeve, ensure that
the latching ears click into place to maintain the IP65 sealing.
Panel
cut-out
10mm
-0 -0 (0.4in)
+0.6
-0 -0
+0.02
Heating
Output
Cooling
Output
of the
rear
- -
1
Recommended minimum
spacing of controllers for
both sizes
38mm
(1.5in)
(Not to
)
scale
1A + L
or Logic
1B - N
LA
2A LB
+
or Logic
2B LC
-
AA
AB
AC
VI
Sensor
V+
input
V-
Model 2208L
HA026202 Issue 2 15/07/99
Line
85-264Vac
Neutral
Ground
Setpoint 2
Standby
Common
Alarm
Output
+
T/C
Pt100
-
