Heli-Professional REVOLUTION 500E BASIC Assembly Instruction And Manual page 10

11
7
Normteile/Standard Parts
M3x20 Schraube
17
Hex Socket Screw
M3 Stopmutter
18
Lock Nut
62
Pitch
65
62
Roll
64
Nick
63
Kugelpfanne
62
Ball Link
1x
Doppelkugelkopf
1x
63
Double Ball Link
1:1
18
4x
Doppelkugelkopf
64
Double Ball Link
Schubstange
65
1x
Control Rod
Beide Schubstangen müssen gleich lang sein!
Both control rods must have the same length!
17
Pitch
66
2x
Taumelscheibe
66
Swash Plate
2x
62
65
63 mm
62
Roll
64
1x
2x Pitch
