- Page 1 INSTRUCTION BOOK FOR IDEA™ Panoramic...
-
Page 2: Tools Required For Assembly
Preparation Note: It requires at least four people to assemble an IDEA Choose a clean work area for assembly using padded material or Panoramic. To maintain optimal projected image geometry and other soft, clean materials. The work area should be larger than screen alignment, a flat and straight wall free from obstructions the overall screen size and directly in front of the location where and angular distortions should be used. - Page 3 Do not use spray cleaner in combination with the foam eraser. Thorough Cleaning: For periodic full screen cleaning or to clean persistent marks from dry erase markers, use the supplied Da-Lite spray cleaner and cleaning cloth. Use clean or dry sections of the microfiber cloth when erasing the screen. This is important to prevent smearing on the screen while cleaning.
- Page 4 Assembly Instructions for Panoramics with 24” Marker Tray Carefully unpack unit and place all panels on top of the clean 5. Use ⅜” open wrench or socket driver and (4) 10-32 nuts to attach work area. The viewing surface of each panel must face down. seam brace onto the studs on the top and bottom of screen frame at the panel seam.
- Page 5 Wall Mounting for Panoramics with 24” Marker Tray NOTE: The screen is shipped with four wall brackets and lengths 2. Secure the two side panel wall brackets to wall studs at the height shipped vary by screen size. Two brackets will be used on the selected in Step 1.
- Page 6 Wall Mounting Instructions for Screens with 24” Marker Tray (continued) 5. Repeat Steps 3-4 to install the (4) remaining L-brackets for the side 6. Using all four people, carefully lift the fully assembled three panel panels. screen to an upright position and place underneath the mounted wall and L-brackets.
- Page 7 Assembly Instructions for Panoramics with Full Length Marker Tray Carefully unpack unit and place all panels on top of the clean 5. Use ⅜” open wrench or socket driver and (4) 10-32 nuts to attach work area. The viewing surface of each panel must face down. seam brace onto the studs on the top and bottom of screen frame at the panel seam.
- Page 8 Wall Mounting for Panoramics with Full Length Marker Tray NOTE: The screen is shipped with four wall brackets and lengths 2. Secure the two side panel wall brackets to wall studs at the shipped vary by screen size. Two brackets will be used on the height selected in Step 1.
- Page 9 Wall Mounting for Panoramics with Full Length Marker Tray (continued) Steps 3-8 require at least four people. Place one person on the screen to an upright position and then place back on the clean far left end of the screen, one person at the left panel seam, work area with the viewing surface of each panel facing up.
- Page 10 Wall Mounting for Panoramics with Full Length Marker Tray (continued) 7. Using all four people, carefully lift the fully assembled three panel screen with the marker trays to an upright position and briefly place underneath the mounted wall brackets. The screen will be parallel to the wall at the end of this step.
- Page 12 Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option) the defective part of the merchandise. Returns for service should be made to your Da-Lite dealer. If it is necessary for the dealer to return the screen or part to Da-Lite, transportation expenses to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in shipment.
