The
POWER
In
PRESENTATION PRODUCTS
DA-LITE SCREEN COMPANY, INC.
Instruction Book for
3100 North Detroit Street
Post Office Box 137
Warsaw, Indiana 46581-0137
IMAGER
Phone: 574-267-8101
800-622-3737
Fax: 574-267-7804
Toll Free Fax: 877-325-4832
www.da-lite.com
e-mail: info@da-lite.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Da-Lite IMAGER
Summary of Contents for Da-Lite IMAGER
- Page 1 POWER PRESENTATION PRODUCTS DA-LITE SCREEN COMPANY, INC. Instruction Book for 3100 North Detroit Street Post Office Box 137 Warsaw, Indiana 46581-0137 IMAGER Phone: 574-267-8101 800-622-3737 Fax: 574-267-7804 Toll Free Fax: 877-325-4832 www.da-lite.com e-mail: info@da-lite.com...
-
Page 2: Installation
LARGE WALL BRACKET (47" LONG) Quantities vary by screen size: Screens 80" and smaller viewing width = 1 Screens over 80" to 96" viewing width = 2 QUANTITY INCLUDED __________ Screens over 96" viewing width = 3 Installation screws not included #10 SCREW SNAP STUD Quantity = 16... - Page 3 SETTING UP YOUR SCREEN TOOLS REQUIRED: Phillips Screwdriver Carpenter’s Level Tape Measure FRAME ASSEMBLY 1. Place the four frame pieces on a clean floor. 2. Slide the frame pieces together at corners. (Note: Frame assembly holes may not appear to fit properly at the corners until all fasteners have been attached.
- Page 4 METHOD 1 (SCREENS 80" AND SMALLER IN METHOD 2 (SCREENS OVER 80" UP TO 96" IN VIEWING WIDTH) VIEWING WIDTH) Method 2 1. Secure the large wall bracket to wall studs at LARGE WALL the desired height. Make sure the large bracket BRACKET is level.
- Page 5 METHOD 3 (SCREENS OVER 96" IN VIEWING CLEANING WIDTH) 1. Secure the large wall brackets to wall studs at Da-Tex ® , Dual Vision, Pearlescent, Cinema Vision, the desired height. Make sure the brackets are Da-Mat ® , High Contrast Da-Mat ®...
- Page 6 Printed in U.S.A. 86478 Rev. 1/08...
