- Page 1 V 2.0 DAT Recorder Setup Guide DAT Recorder Setup Guide DAT Recorder Setup Guide DAT Recorder Setup Guide Revised: 04-12-00...
-
Page 2: Table Of Contents
Digital 328 v2 and DAT Digital 328 v2 and DAT Digital 328 v2 and DAT Digital 328 v2 and DAT Recorder Setup Guide Recorder Setup Guide Recorder Setup Guide Recorder Setup Guide Contents DAT Recorders Without BNC Wordclock Input 1 1 1 1... -
Page 3: Dat Recorders Without Bnc Wordclock Input
The Auxiliary Optical Output on the 328 transmits a signal in ADAT NOTE format, not optical S/PDIF format. If the DAT recorder has S/PDIF I/O, the system should be configured thus: Dat Recorder S/PDIF 328 S/PDIF Out 328 S/PDIF In Dat Recorder S/PDIF In Spirit Digital 328 v2... - Page 4 If the DAT recorder has AES/EBU I/O, the system should be configured thus: Dat Recorder AES/EBU 328 AES/EBU Out Recorder AES/EBU In 328 AES/EBU In DAT Recorder Setup Guide...
-
Page 5: Digital 328 Setup
Press <MENU>, and use the PARAM encoder to scroll down until ‘Clock Source Sel’ is the highlighted menu. Press <ENTER> and set the 328 to slave to the clock at the AES/EBU or S/PDIF input: <Wordclock Src.> <Wordclock Src.> External:AES/EBU External: SPDIF Spirit Digital 328 v2... - Page 6 S/PDIF Input And Output Configuration S/PDIF Input And Output Configuration S/PDIF Input And Output Configuration S/PDIF Input And Output Configuration S/PDIF Input: Press <MENU>, and use the PARAM encoder to scroll down until ‘SPDIF I/P Setup’ is the highlighted menu. Press <ENTER> and route the S/PDIF input as required, from a choice of stereo inputs 1 and 2, FX returns 1 and 2 or as a dedicated 2 Track input.
- Page 7 <AES/EBU Output> <AES/EBU Output> S/Rate Flag:44k1 Pro Flag: * Individual DAT recorder models may require different settings. NOTE Consult the DAT Recorder Setup section of this setup guide and documentation specific to the DAT recorder model. Spirit Digital 328 v2...
-
Page 8: Dat Recorder Setup
DAT Recorder Setup DAT Recorder Setup DAT Recorder Setup DAT Recorder Setup Generally, the DAT recorder will have to be set up to record from the digital AES/EBU or S/PDIF input rather than the analogue input. Consult your DAT recorder manual for precise details of how this should be done. -
Page 9: Notes On Specific Dat Recorders
DA-302 input, indicated on the DA-302 input meters. ‘Digital’ must be selected as input source on input selection switch. Input source select switch <MARGIN RESET> switch Spirit Digital 328 v2... -
Page 10: Tascam Da-20 Mkii
Tascam DA-20 MkII The Tascam DA-20 MkII detects clock frequency from the 328 S/PDIF output sample rate flag setting and not the 328 internal clock frequency (see page 5). Consequently the sample rate flag setting should be set to the same as the 328 internal clock, or if the 328 is slaving to another external source, to the sample rate of that source. -
Page 11: Panasonic Sv-3800
>>| key. This should be set to AES for the AES/EBU output or IEC-C for the coaxial S/PDIF output. This must also be set for the SV-3800 input. Press counter <RESET> to return. <PAUSE> Skip >>| Counter <MODE> and counter <RESET> Spirit Digital 328 v2... -
Page 12: Dat Recorders With Bnc Wordclock Input
DAT Recorders With DAT Recorders With DAT Recorders With DAT Recorders With BNC Wordclock Input BNC Wordclock Input BNC Wordclock Input BNC Wordclock Input Connecting The System Connecting The System Connecting The System Connecting The System If the DAT recorder is to be connected to the 328 for use with S/PDIF I/O, the system should be configured thus: DAT Recorder S/PDIF 328 S/PDIF Out... - Page 13 328 AES/EBU Out DAT Recorder AES/EBU Dat Recorder AES/EBU In 328 AES/EBU In 328 BNC Wordclock Out Dat Recorder BNC Wordclock The digital audio connections and the BNC wordclock connection must NOTE both be made Spirit Digital 328 v2...
-
Page 14: Digital 328 Setup
Digital 328 Setup Digital 328 Setup Digital 328 Setup Digital 328 Setup Wordclock Wordclock Wordclock Wordclock The DAT recorder should be set to slave to the clock present at the BNC wordclock input. The manual supplied with the DAT recorder should be consulted on how this should be done. The same clock source should then be used for both playback and record of the DAT recorder. - Page 15 ‘NOWHERE’, which is the default setting, in which case the signal is muted. < AES/EBU Input > Route To: 2TRK Assigning the S/PDIF input will override any analogue signal present at NOTE the selected input. The S/PDIF and AES/EBU inputs cannot be routed to the same input simultaneously. Spirit Digital 328 v2...
- Page 16 AES/EBU Output: Press <MENU>, and use the PARAM encoder to scroll down until ‘AES/EBU O/P Set.’ is the highlighted menu. Press <ENTER> and route the AES/EBU output as required, from a choice of the mix bus, aux outputs 1/2 or 3/4, or FX sends 1/2. <AES/EBU Output>...
-
Page 17: Dat Recorder Setup
Consult your DAT recorder manual for precise details of how this should be done. The DAT recorder must be set to slave to the clock present at the BNC wordclock input. Consult your DAT recorder manual for precise details of how this should be done. Spirit Digital 328 v2...
