- Page 1 A A p p p p e e n n d d i i x x In this Section: MIDI Implementation Connection Diagrams Signal Flow Diagram Digital 328 Expanded Surface Diagram Cable Connection Diagrams Spirit Digital 328 Users Guide Version 2...
-
Page 2: A - Midi Implementation
8VHU 6HWXS UHFDOO 0RGH 201, 21 32/< 0RGH 201, 21 0212 R <(6 0RGH 201, 2)) 32/< 0RGH 201, 2)) 0212 [ 12 Spirit Digital 328 Users Guide Version 2... - Page 3 3 3 2 2 8 8 SPIRIT DIGITAL Appendix A-2 MIDI Automation Specifications The tables below outline the MIDI Channels, Continuous Controller Id’s and associated ranges of the automatable parameters of the Digital 328. TABLE 1: SURFACE CONTROLS Spirit Digital 328 Users Guide Version 2...
- Page 4 3 3 2 2 8 8 SPIRIT DIGITAL TABLE 1: SURFACE CONTROLS CONT. Spirit Digital 328 Users Guide Version 2...
- Page 5 3 3 2 2 8 8 SPIRIT DIGITAL TABLE 2: INTERNAL FX AND DYNAMICS MENUS Spirit Digital 328 Users Guide Version 2...
- Page 6 3 3 2 2 8 8 SPIRIT DIGITAL TABLE 2: INTERNAL FX AND DYNAMICS MENUS CONT. Spirit Digital 328 Users Guide Version 2...
- Page 7 3 3 2 2 8 8 SPIRIT DIGITAL TABLE 3: DYNAMICS ROUTING Spirit Digital 328 Users Guide Version 2...
-
Page 8: System Exclusive Implementation
A remote request will be deemed invalid by the Digital 328 if the request cannot be performed or is out of range. Appropriate validity responses are transmitted by the console from the MIDI Out port, as defined in the Specific Instructions section below. Spirit Digital 328 Users Guide Version 2... -
Page 9: Specific Instructions
Remote request: F0H, 39H, 01H, dev, 00H, aa, bb, F7H [328 Rx] aa = MIDI dump of automatable parameters' MIDI CC values request bb = 00H - 01H Automation data / MIDI controller bank values Spirit Digital 328 Users Guide Version 2... - Page 10 MIDI dump of automatable parameters' MIDI CC values request received bb = 00H - 01H Automation data / MIDI controller bank values FOLLOWED IMMEDIATELY BY DUMP OF AUTOMATABLE PARAMETERS' / MIDI CONTROLLERS' ASSOCIATED MIDI CONTINUOUS CONTROLLER VALUES AS REQUESTED Spirit Digital 328 Users Guide Version 2...
- Page 22 3 3 2 2 8 8 SPIRIT DIGITAL Spirit Digital 328 Users Guide Version 2...
