LawnMaster CLMB4016K Operator's Manual

16" 40v max* lithium-ion cordless mower
Hide thumbs Also See for CLMB4016K:
Table of Contents

Advertisement

Quick Links

Operators Manual / Guide d'Utilisation
EN p. 2
FR p. 32
MNL_CLMB4016K_V1
Read all safety rules and instructions carefully before operating this tool.
Distributed By Cleva North America 601 Regent Park Court Greenville, SC 29607 (866)-384-8432
Lisez toutes les règles et consignes de sécurité avant d'utiliser cette tondeuse.
Distribuée par Cleva North America 601 Regency Park Court, Greenville, SC 29607 (866)-384-8432
16" 40V MAX* Lithium-Ion Cordless Mower CLMB4016K
Tondeuse Sans Fil CLMB4016K 40V MAX* 406 mm (16 po)
* Maximum initial battery workload voltage (measured without a workload) is 40 volts.
Nominal voltage is 36 volts
* Tension batterie de la charge de travail initiale maximale (mesurée sans charge de travail)
est de 40 volts.
Tension nominale est de 36 volts

Advertisement

Table of Contents
loading

Related Manuals for LawnMaster CLMB4016K

Summary of Contents for LawnMaster CLMB4016K

  • Page 1 EN p. 2 16" 40V MAX* Lithium-Ion Cordless Mower CLMB4016K FR p. 32 Tondeuse Sans Fil CLMB4016K 40V MAX* 406 mm (16 po) * Maximum initial battery workload voltage (measured without a workload) is 40 volts. Nominal voltage is 36 volts * Tension batterie de la charge de travail initiale maximale (mesurée sans charge de travail)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONTENTS SPECIFICATIONS INTRODUCTION GENERAL SAFETY RULES SPECIFIC SAFETY RULES SYMBOLS 9-10 FEATURES 11-13 ASSEMBLY 13-19 OPERATION 20-21 BATTERY CHARGER 21-22 MAINTENANCE 22-26 ENVIRONMENTAL SAFE BATTERY DISPOSAL TROUBLESHOOTING WARRANTY EXPLODED VIEW / PARTS LIST 29-30 NOTES SPECIFICATIONS 40V CORDLESS MOWER Battery Type 40V MAX* Lithium-Ion Charger Time...

  • Page 3: Introduction

    INTRODUCTION This product has many features for making its use more pleasant and enjoyable. Safety,performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. GENERAL SAFETY RULES WARNING This symbol indicates important safety instructions. If these instructions are not followed, it could endanger the personal safety and/or property of the operator and others.
  • Page 4 GENERAL SAFETY RULES • Carefully read all instructions on the mower and in the manual before attempting to assemble and operate the mower. Keep this manual in a safe place for future reference, and consult it regularly. • Do not use the lawn mower in damp or wet conditions or operate in the rain. •...
  • Page 5 CAUTION USE ONLY LAWNMASTER APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE MOWER. Use with LAWNMASTER 40V Lithium-lon battery.

  • Page 6: Specific Safety Rules

    SPECIFIC SAFETY RULES BATTERY SAFETY RULES • Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in operating condition. Be aware of possible hazards when not using your battery tool or when changing accessories. Following this rule will reduce the risk of electric shock, fire, or serious personal injury.
  • Page 7 CAUTION USE ONLY LAWNMASTER APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE MOWER. Use with LAWNMASTER 40V Lithium-lon battery. Ensure that the device is switched off before inserting the battery. Inserting a battery into a power tool that is switched on may result in accidents.

  • Page 8: Specific Safety Rules

    SPECIFIC SAFETY RULES Do not operate the charger on a combustible surface (e.g. paper, textiles). Risk of fire due to heating during charging. If the power cord for this equipment is damaged, it must be replaced by the manufacturer, a customer service agent of the same or qualified person in order to prevent hazards.

  • Page 9: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. Volts Voltage Direct Current Type or a characteristic of current Amperes Current Hertz...

  • Page 10: Symbols

    SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBO SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, DANGER: will result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, WARNING: could result in death or serious injury.

  • Page 11: Features

    FEATURES Fig. 1...
  • Page 12 FEATURES KNOW YOUR LAWN MOWER (See Fig 1) The safe use of this product requires an understanding of the information on the product and in this operator’s manual as well as a knowledge of the project you are attempting. Before use of this product, familiarize yourself with all operating features and safety rules. 1.

  • Page 13: Assembly

    FEATURES PACKING LIST Mower Safety Key (must be installed for mower to work) Mulch Plug - Comes installed from factory at rear of mower Grass Collection Bag Assembly Battery Charger 40V Lithium-Ion Battery Hardware Pack Operator’s Manual NOTE: The safety key must be installed for mower to operate. The safety key only fits into the switch in one direction.
  • Page 14 ASSEMBLY ASSEMBLING THE HANDLE (See Figs. 2-3) ■ Insert lower handles (6) ONTO and over the exposed Attachment plate bolts at the rear of the motor housing. Make sure the power cord clips (3) on the handles are BOTH facing up. On each side, place washer (21) over bolt tip and thread locking lever (4) onto it.
  • Page 15 ASSEMBLY ASSEMBLING THE REDI BAG (COLLECTION BAG) (See Figs. 6) ■ Your Lawnmaster mower comes with a tool-less collection bag (15). Your REDI-bag ships flat as shown. ■ To assemble the REDI-bag straighten the hinged steel frame at opening of bag as shown.

  • Page 16: Intended Use

    Fig. 9 INTENDED USE This cordless lawnmower is designated with the LawnMaster 40V Lithium-Ion battery. The product is intended for mowing and mulching grass in domestic yards only. It must not be used to mow unusually high, dry or wet grass, e.g. pasture grass, or for shredding leaves.
  • Page 17 ASSEMBLY Fig. 10 Fig. 9 SETTING CUTTING HEIGHT (See Fig. 10) When shipped, the wheels (9) on the mower are set to a low-cutting position. Before using the mower for the first time, adjust the cutting position to the height best suited for your lawn. The average lawn should be between 1"...

  • Page 18: Installing The Mulching Plug

    ASSEMBLY HANDLE TILT ADJUSTMENT ■ The tilt of the handle can be adjusted. ■ Secure the lower handle [6] with the locking lever [4] according to your preference (Fig. 12). Fig. 12 EMPTYING Empty the collection bag (15) frequently during use. Do not wait until it is completely full. We recommend emptying it when it is half full.
  • Page 19 ASSEMBLY iPOWER MOWER MODE INDICATOR (10a) (See Fig. 16) Located on upper mower handle ■ By default, the motor power is set to “AUTO” and will automatically adjust to your lawn. ■ Push the press button repeatedly to cycle through the different motor power levels.

  • Page 20: Operation

    OPERATION STARTING / STOPPING ■ To switch on, insert the safety key (12), press and hold the safety switch button (2) and gently pull the Start/stop bale switch (1) (Fig. 17-19). Once started, release the safety safety switch button (2). ■...

  • Page 21: Battery Charging

    OPERATION Mow in slight overlapping rows. The most effective pattern for mowing lawns is straight lines along one of the sides. This will keep the rows even and ensures that all the lawn is cut without missing any spots (Fig.21). Fig.

  • Page 22: Maintenance

    BATTERY PACK AND CHARGER ■ A flashing red LED light on the charger indicates that the battery temperature is not within -5 °C– 50 °C or the charging current is too high. ■ After continuous or repeated charging cycles without interruption, the charger may warm up. This is normal and does not indicate a technical defect of the battery charger.
  • Page 23 REPLACING THE MOWER BLADE (See Figs. 23 24) NOTE: Remove safety key and battery before performing any maintenance!! NOTE: Only use identical replacement blades. LawnMaster mower blade replacement part #RMB4016K. • Stop the motor and allow the blade to come to a complete stop.
  • Page 24 MAINTENANCE ■ Loosen the blade nut using a wrench or socket (not provided). ■ Remove the blade nut clounterclockwise then remove the blade. ■ Make certain the fan assembly is pushed completely against the motor shaft. ■ Place the new blade on the shaft against the fan assembly. Make sure it is installed with the curved ends pointing up toward the mower deck (17) and not down toward the ground.
  • Page 25 MAINTENANCE ■ Using a fine-tooth file or sharpening stone, sharpen cutting edges on both ends of the blade, removing equal amounts of material from both ends. WARNING When removing, inspect the blade carefully. If blade is bent or damaged, replace immediately with a new blade.

  • Page 26: Environmental Safe Battery Disposal

    MAINTENANCE ■ Push inward on each side of the lower handle (6), and lift the sides of the lower handle (6) past the edges of the handle mounting brackets. ■ Fold the lower handle (6) forward, making sure not to bend or kink the power cord. Fig.

  • Page 27: Troubleshooting

    The mower is The motor shaft is bent. Stop the motor, and inspect for damage. excessively noisy and vibrates. The blade is unbalanced. See Blade Balancing Section in this manual. OR replace using LawnMaster replacement mower part #CLMB4016K.

  • Page 28: Warranty

    WARRANTY We take pride in producing a high quality, durable product. This Lawnmaster® product carries a limited two (2) year warranty against defects in workmanship and materials from date of purchase under normal household use. If product is to be used for commercial, industrial or rental use, a 30 day limited warranty will apply.

  • Page 29: Exploded View / Parts List

    EXPLODED VIEW / PARTS LIST...

  • Page 30: Exploded View / Parts List

    EXPLODED VIEW / PARTS LIST CLMB4016K MANUAL PARTS LIST Quantity Drawing Number Description Key Number GMB0BX.20.04 Safety Flap GM01BX.00.09 Safety Flap Axle TOTHYN.05.09 Safety Flap Spring Motor Cover Assy GMD1BX.20.01.X1.03 Rear Wheel TGQTGL.62.00.X1.03 BOC2YX.14.NS Rear Locking Hubcap GM90BX.00.03 Base Connector TOQTGX.X0.01...

  • Page 31: Notes

    NOTES...
