Transmitter Specifications
Type of multiplexing
Normal output power
TX Max power
Frequency range
Frequency stability
Bandwidth
Occupied bandwidth
Modulation method
Waveform quality
Conducted spurious emission
Common RF impedance
4A: Technical Specifications
EVDO and 1xRTT
7-10 dBm
23 dBm
1850MHz to 1919MHz
Compliant with CDG1
1.25MHz
1.25MHz
O-QPSK/HPSK
.944
Complies with Title 47, Part 24 of
the FCC Rules
50ohms
61
