Image Compression (if applicable): Indicates that data and image
compression is enabled for enhanced speed performance.
Transfer/Receive: Visual indicator of data activity
Signal Strength: Visual indicator of signal strength
Detail Drawer: Displays byte counter. Click + to expand and - to close.
The Menu Button
Clicking the Menu button, located in the upper-left corner of
the interface, provides access to the Sprint PCS Connection Manager
Software menu.
Some menu options will remain inactive/unavailable if a connection has
not been established. Once a connection is made, the options will become
active. The Links menu option and the Settings menu option both contain
submenus. See Section 2C, Menu Options, beginning on page 31, for
details on the Sprint PCS Connection Manager options and settings.
2B: Sprint PCS Connection Manager Software 25
