Page 1: Operating Instructions
MK-377 TILE SAW www.mkdiamond.com OWNER'S MANUAL OPERATING INSTRUCTIONS & PARTS LIST Revision 102 06.2014 Manual Part# 160030 Caution: Read all safety and operating instructions before using this equipment. This parts list MUST accompany the equipment at all times. - Page 2 INTRODUCTION Congratulations on your purchase of a MK-377 Saw. We are certain that you will be pleased with your purchase. MK Diamond takes pride in producing the finest construction power tools and diamond blades in the industry. Operated correctly, your MK-377 Saw should provide you with years of service. In order to help you, we have included this manual.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY Safety Messages Damage Prevention Message General Safety Precautions Hazard Symbols California Proposition 65 Message Electrical Requirements and Grounding Instructions 8-11 Safety Label Locations Product Specifications UNPACKING, TRANSPORT Unpacking Contents Transport STARTUP, ADJUSTMENT, OPERATION and SHUTDOWN Cutting Head Installation Diamond Blade Installation 15-16 Adjustable Cutting Guide Installation... -
Page 4: Safety Messages
MK-377 SAW SAFETY Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. Safety warnings and guidelines do not by themselves eliminate danger. - Page 5 MK-377 SAW SAFETY KEEP CHILDREN AWAY All visitors and children should be kept a safe distance from work area. MAKE THE WORKSHOP KID PROOF Make the workshops kid proof by using padlocks, master switches or by removing starter keys. DO NOT FORCE THE TOOL A power tool will do a job better and safer operating at the rate for which it was designed.
-
Page 6: Hazard Symbols
MK-377 SAW SAFETY USE RECOMMENDED ACCESSORIES Consult the owner’s manual for recommended accessories. Using improper accessories may increase the risk of personal or by-stander injury. Unauthorized equipment modifications will void all warranties. Manufacturer does not assume responsibility for any accident due to equipment modifications. - Page 7 MK-377 SAW SAFETY WARNING Diamond Blades improperly used are dangerous. Comply with American National Standards Insti- tute Safety Code, B7.1 and, Occupational Safety and Health Act covering Speed, Safety Guards, Flanges, Mounting Procedures, General Operating Rules, Handling, Storage and General Machine...
-
Page 8: California Proposition 65 Message
MK-377 SAW SAFETY SILICA DUST WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis. - Page 9 MK-377 SAW SAFETY WARNING To avoid the possibility of the appliance or plug receptacle getting wet, position the machine to one side of a wall mounted receptacle. This will prevent water from dripping into the receptacle or plug. A "drip loop," shown in the picture below, should be arranged by the user to properly position the power cord relative to the power source.
- Page 10 MK-377 SAW SAFETY ELECTRIC MOTOR SAFETY For maintenance care and operation of the electric motor, refer to your electric motor instruction book- let furnished with the electric motor. Protect the electric motor from dust as much as possible and keep ventilating openings clean.
- Page 11 MK-377 SAW SAFETY WARNING The “drip loop” is that part of the cord below the level of the recep- tacle, or the connector, if an extension cord is used. This method of positioning the cord prevents the travel of water along the power cord and coming in contact with the receptacle.
-
Page 12: Safety Label Locations
MK-377 SAW SAFETY LABELS SAFETY LABEL LOCATIONS Safety labels contain important safety information. Please read the information contained on each safety label. These labels are considered a permanent part of your saw. If a label comes off or becomes hard to read, contact MK Diamond or your dealer for a replacement. -
Page 13: Product Specifications
General Description The MK-377 Tile Saw is engineered as a tabletop wet tile saw. The saw includes a powerful 120V electric motor. The saw is capable of cutting tile up to fourteen (14) inches in length. The saw can cut an object two (2) inches thick in one pass. -
Page 14: Unpacking
This warranty DOES NOT cover normal wear or damage resulting from operator abuse. In no event shall MK Diamond Products, Inc. be liable for consequential damages arising out of the failure of any product if operated improperly. MK Diamond Products may act as a warranty station for motor/en- gine repairs based on an individual agreement with the manufacturer. -
Page 15: Cutting Head Installation
MK-377 SAW INSTALLATION Follow the assembly instructions to prepare your MK-377 for operation. CUTTING HEAD INSTALLATION Loosen the Blade Guard Remove the Blade Guard Locate and remove the three Retaining Knob Wingnut and then remove Cutting Head Retaining the Blade Guard... - Page 16 MK-377 SAW INSTALLATION Place the Blade Wrench on the Install Diamond Blade onto Verify the Directional Arrow of Blade Retaining Nut and remove Blade Shaft the Blade faces outward and the Blade Retaining Nut and matches the Directional Arrow of...
-
Page 17: Adjustable Cutting Guide Installation
MK-377 SAW ASSEMBLY ADJUSTABLE CUTTING GUIDE INSTALLATION NOTE: The Adjustable Cutting Guide can be used on either side of the Diamond Blade. Loosen Adjustable Cutting Guide Place the Adjustable Cutting Guide retaining thumbscrew and place it over onto the Movable Cutting and tighten... -
Page 18: Water Pump Preparation
MK-377 SAW ASSEMBLY Inspect the MK-377 for Verify the Movable Cutting damage – ensure the cord is Table moves freely free of cracks or cuts WATER PUMP PREPARATION Connect the Cooling Transfer Place the Water Pump in the Press the end of the Cooling... -
Page 19: Setup For Operation
OPERATION SETUP FOR OPERATION CAUTION 1. Before connecting the MK-377 to a power supply, be sure the voltage, cycle and phase meet the requirements of table below. 2. If using an extension cord, make sure the length and wire gauge correspond to the requirements listed in the table on page 10. -
Page 20: Adjustment & Operation
MK-377 SAW OPERATION ADJUSTMENT & OPERATION CAUTION DO NOT FORCE THE TOOL. It will do the job better and safer at the rate for which it was designed. Loosen the retaining thumbscrew Place the tile against the Turn the motor ON and verify proper... -
Page 21: Cleanup
CAUTION Ensure the saw is disconnected before completing the remainder of the cleanup process. Fill the Water Pan with Run the MK-377 until clear Dispose of the contents of water is seen at the blade clean water the Water Pan and clean the cooling ports (Approx. -
Page 22: Lockout
Assembly LOCKOUT The MK-377 is equipped with a lockout device that can be used during maintenance and troubleshooting to render the saw in operable. The lockout can also be used to prevent unauthorized use. Locate the Lockout Pin in the... -
Page 23: Blade Dressing
When this occurs, the blade will need to be dressed. The diamond blade can be dressed using the MK Dressing Stick (part# 152972) and by following the steps below. Setup the MK-377 for operation Set the Adjustable Cutting... -
Page 24: Motor Brush Change Out
MK-377 SAW MAINTENANCE MOTOR BRUSH CHANGE-OUT Disconnect the tool before servicing and when changing accessories, such as WARNING blades and bits. Locate and loosen one Motor Remove the Motor Brush Remove the old Motor Brush Brush Housing Cover using a flat... -
Page 25: Troubleshooting
MK-377 SAW TROUBLESHOOTING TROUBLESHOOTING Blade will not cut properly. Check for Smoothness or Check for proper rotation Ensure the Blade Core is not "Glazing" (Dress blade if needed) bent and Arbor is not out of round Verify the blade is correct for the... - Page 26 MK-377 SAW TROUBLESHOOTING NOTE: "Rodding" cooling channels is performed by inserting a small wire rod through the cooling inlet on top of the Blade Guard and directing the rod out through each of the cooling flow tubes located on the underside of the Blade Guard. The cooling channels should be "rodded"...
- Page 27 MK-377 SAW TROUBLESHOOTING BLADE STOPS TURNING Check the ON/OFF Switch is in Verify all plugs are fully Check to see if the Ground Fault the ON position connected Circuit Interrupter (GFCI) tripped Verify the circuit breaker is at least Verify circuit breaker not...
- Page 28 MK-377 SAW EXPLODED VIEW...
-
Page 29: Accessories
MK-377 SAW PARTS LIST Item Description Part # Accessories Wrench, Blade Nut, 15/16 Boxed End 134684 Wrench, Blade Shaft, 11/16 Open End 153450 Blade, 7 Dia X 5/8 arbor MK-170 153441 Owner’s Manual, 377 160030 Warranty Card 155037 Assembly, Rip Guide 134551 w/ Screw, 1⁄4 –20 x 3⁄4 Thumb... - Page 30 MK-377 SAW PARTS LIST Assembly, Roller Wheel, Double 156586 Bracket, Roller Wheel 156522 Wheel, Roller 151799 Screw, 1/4-20 X 1 1/2 Hex Head Cap 151914 Washer, 1/4 SAE Flat 151915 Nut, 1/4-20 Hex 151893 Assembly, Splash Curtain 155901-MK Curtain, Splash...
- Page 31 NOTES...
- Page 32 MK-377 SAW ACCESSORIES ITEM NUMBER DESCRIPTION MK-200, 7" x 5/8 Arbor 139295 Premium grade Diamond Blade for smooth, chip-free cutting on tile. MK-215, 7" x 5/8 Arbor Supreme grade diamond blade for hard 139311 materials MK-315, 7" x 5/8 Arbor...
- Page 33 NOTES...
-
Page 34: Ordering Information
MK-377 SAW ORDERING & RETURN ORDERING INFORMATION You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. When ordering direct from MK Diamond, please have the following information ready before calling: •... -
Page 35: Contact & Warranty
© COPYRIGHT 2014, MK DIAMOND PRODUCTS, INC. ALL RIGHTS RESERVED. The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their re- spective owners and used with permission. - Page 36 MK-377 TILE SAW OWNER'S MANUAL & OPERATING INSTRUCTIONS MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 421-5830 Phone: (310) 539-2221 Fax: (310) 539-5158 www.mkdiamond.com...
