MK-101 Tile Saw
OWNERS MANUAL, PARTS LIST &

OPERATING INSTRUCTIONS

Revision 101
04.2011
Manual Part# 153754
Caution: Read all safety and operating instructions
before using this equipment. This owner's manual
MUST accompany the equipment at all times.

Advertisement

Table of Contents
loading

Related Manuals for MK Diamond Products MK-101

Summary of Contents for MK Diamond Products MK-101

  • Page 1: Operating Instructions

    MK-101 Tile Saw OWNERS MANUAL, PARTS LIST & OPERATING INSTRUCTIONS Revision 101 04.2011 Manual Part# 153754 Caution: Read all safety and operating instructions before using this equipment. This owner’s manual MUST accompany the equipment at all times.

  • Page 2: Exploded View And Parts List

    MK-101 eXPlODeD View aND PaRTS liST...
  • Page 3 MK-101 eXPlODeD View aND PaRTS liST...
  • Page 4 DRESSING STICK, 8 X 2 X 1, 60 GRIT 152792-RW EXTENSION, 2.25 X 3/4 DIA. BELT GUARD 155711 CORD, TWIST-LOCK GFCI, 120V/15A 157421 OWNER’S MANUAL, MK-101 153754 CARD, MK WARRANTY REGISTRATION 155037 LABEL, DO NOT RETURN 157063 SELL SHEET, TILE ACCESSORY...
  • Page 5 SCREW, 1/4-20 X 1 1/4 HEX HEAD CAP 157145 WASHER, 1/4 SPLIT LOCK 152591 SHEET, CUTTING HEAD STOP INSTRUCTION 157728-IS CUTTiNG HeaD aSSeMBlieS ASSEMBLY, DC CUTTING HEAD, MK-101 158478 BelT GUaRDS BELT GUARD, MK-101 (COMP) 158319-01 BRACKET, INNER BELT GUARD, 100/101 158611...
  • Page 6 MK-101 eXPlODeD View aND PaRTS liST iTeM DeSCRiPTiON PaRT # PULLEY, 6J17 X 5/8 BORE 158214 KEY, 3/16 X 3/16 X 1-1/8 SQUARE 150344 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET, CUP POINT 157083 LABEL, WARNING MOST MOTOR..., 2 3/4 X 2 7/16...
  • Page 7 WING NUT, 5/16-18 NYLOCK 151746 STRAP, MOTOR ADJUSTMENT 152673 SCREW, 3/8-16 X 3 1/2 HEX HEAD FULL THREAD 153147 ASSEMBLY, DC TABLE, MK-101 158477 GUiDe BaRS BAR, 3/4 X 32 GUIDE, 101 134759 COVER, GUIDE BAR, 120° X 35” 158403...

  • Page 8: Theory Of Diamond Blades

    MK-101 THeORY THeORY OF DiaMOND BlaDeS: Diamond blades do not really cut; they grind the material through friction. Diamond crystals, often visible at the leading edge and sides of the rim/segment, remove material by scratching out par- ticles of hard, dense materials, or by knocking out larger particles of loosely bonded abrasive mate- rial.
  • Page 9 MK-101 aCCeSSORieS ACCESSORIES: iTeM NUMBER DESCRIPTION MK-200. 10 X 5/8 ARBOR Premium grade Diamond Blade for smooth, 137166 chip-free cutting on tile. MK-215, 10 X 5/8 ARBOR Supreme grade diamond blade for 128074 hard materials MK-315, 10 X 5/8 ARBOR...

  • Page 10: Ordering And Return Information

    ORDeRiNG aND ReTURN iNFORMaTiON ORDeRiNG iNFORMaTiON: You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. NOTe: There is a $25.00 minimum order when ordering direct from MK Diamond. All purchases must be made using VISA or MasterCard.
  • Page 11 MK-101 Tile Saw OWNERS MANUAL & OPERATING INSTRUCTION DOCUMENT NO. 153754 MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 845-3729 Phone: (310) 539-2221 Fax: (310) 539-5158 www.mkdiamond.com...
