Arkon BBP132 User Manual

PTM132 & BBP132
CM018-KST-2
CM018-KST-2
(B)
(A)
Windshield Installation
Step 1. Push the pedestal suction cup (A) firmly to the windshield.
Flip the lever (B) down to secure the suction cup.
(F)
(E)
(D)
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no
responsibility of liability for injury or death as a result of car crashes
and/or air bag deployment.
Arkon Resources, Inc. is not responsible for any damages caused to
your car, your device, or yourself due to the installation or use of the
pedestal mount.
5" Windshield Suction Mount
PTM132
CC002-Palm
BBP132
CC003-BBP
(B)
Pedestal and Dual-T Head Instructions
Adjust the angle of the arm by loosening the adjustment
Step 1.
knob (D).
(G)
Adjust the angle and rotation of the pedestal head by
Step 2.
loosening the swivel-tightening knob (E).
Step 3. Attach the device cradle to the dual-T tab head (F) by
inserting the T-tabs into the T-slots (G).
Consumer Hotline:
(USA) (800) 841-0884
(INT'L) (626) 254-9005
Mon-Fri. 9am-5pm, PST
Compatability: (not complete)
-HP iPAQ 6815
-Palm Treo 650
-HP iPAQ 6818
-Palm Treo 680
-HP iPAQ 6828
-Palm Treo 700W
-HTC P3600
-Palm Treo 700P
-HTC Neo
-Palm Treo 750
Compatability:
-Blackberry Pearl 8100
Dash Installation (Optional,
when disc is included)
Step 1. Locate a safe flat surface on
the dash or console to
mount the pedestal. Clean
the dash with the alcohol
(A)
pad provided. Let the dash
surface dry before applying
the adhesive disc (C).
Push the pedestal suction
Step 2.
(C)
cup (A) firmly to the disc (C).
Flip the lever (B) down to
secure the suction cup.
The Mobile Mounting Specialists
© Copyright 2007 Arkon Resources, Inc.
-XDA Atom Exec
-Dopod 818 Pro
-Dopod 810
-i-Mate JAMin
TM
www.arkon.com
Arcadia, CA 91006 USA
Made in Taiwan
