Arkon BBP133 User Manual

PTM133 & BBP133
CM019-KST-2
CM019-KST-2
(B) (B)
(A)

Windshield Installation

Step 1.
Push the pedestal suction cup (A) firmly to the windshield.
Flip the lever (B) down to secure the suction cup.
(E)
(D)

Safety Precautions

Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no
responsibility of liability for injury or death as a result of car crashes
and/or air bag deployment.
Arkon Resources, Inc. is not responsible for any damages caused to
your car, your device, or yourself due to the installation or use of the
pedestal mount.
7" Windshield Suction Mount
PTM133
CC002-Palm
BBP133
CC003-BBP
(F)

Compatability: (not complete)

-Palm Treo 650
-Palm Treo 680
-Palm Treo 700W
-Palm Treo 700P
-Palm Treo 750
Compatability:
-Blackberry Pearl 8100
(B)
(C)

Pedestal and Dual-T Head Instructions

Adjust the angle of the arm by loosening the adjustment
Step 1.
knobs (D).
(G)
Adjust the angle and rotation of the pedestal head by
Step 2.
loosening the swivel-tightening knob (E).
Step 3. Attach the device cradle to the dual-T tab head (F) by
inserting the T-tabs into the T-slots (G).
Consumer Hotline:
(USA) (800) 841-0884
(INT'L) (626) 254-9005
Mon-Fri. 9am-5pm, PST
-HP iPAQ 6815 -XDA Atom Exec
-HP iPAQ 6818 -Dopod 818 Pro
-HP iPAQ 6828 -Dopod 810
-HTC P3600 -i-Mate JAMin
-HTC Neo
Dash Installation (Optional,
when disc is included)
Step 1. Locate a safe flat surface on
the dash or console to
mount the pedestal. Clean
the dash with the alcohol
(A)
pad provided. Let the dash
surface dry before applying
the adhesive disc (C).
Step 2. Push the pedestal suction
cup (A) firmly to the disc (C).
Flip the lever (B) down to
secure the suction cup.
The Mobile Mounting Specialists
www.arkon.com
Arcadia, CA 91006 USA
Made in Taiwan
© Copyright 2007 Arkon Resources, Inc.
TM
