INSTRUCTION MANUAL BOOK.
SPECIFICATION
Wingspan
Length
Weight
Parts listing required(not included):
Radio
Servo
Motor
Battery: 3 CELLS - LI - POL Y - 1 1.1v - 2000 mA.h.
Propeller
Speed Control :
:
108 cm
:
100 cm
:
0.85 kg
:
04 channel.
:
04 servos.
:
AXI2814.12.
:
12 x 3.8.
30A
43 in.
39.37 in.
1.87 lbs.
Made in Vietnam.
