9 Technical specifications

9 Technical specifications
EN
9.1

Technical specifications of the PowerRouter

AC output
Continuous output power
AC output current
Cos Phi
Output voltage
Protection
Standby losses
User interface
Connectivity
User-selectable relays
Solar panels
Max. input
No. of inputs
No. of MPP trackers
DC disconnect switch
Solar voltage
MPP voltage
Solar connections
Max. efficiency
Max. MPP efficiency
Environmental
Operating temperature range (full power)
Storage temperature
Humidity
Regulatory approvals and standards
Safety
Emission
Immunity
Anti-islanding protection
Warranty
40
PowerRouter • Solar Inverter • Installation manual
PR50S PR37S
5000 W (DE: 4600 W) 3700 W (DE/UK/PT:
3680 W)
25 A (DE: 22A) 18 A
1 (DE, IT: 0.9 ind. ... 0.9 cap. adjustable)
230 Vac ± 2% , 50 Hz ± 0.2 %
(180-264 Vac, 45-55 Hz , limited by local anti-islanding requirements)
electronic, fused
< 3W
display with 4-button operation
ethernet (RJ45), TCP/IP
2 provided. NO/NC, 250Vac, 1 A, 24 Vdc, 5 A
PR50S PR37S
5.5 kWp total, 15 A per 4 kWp total, 15 A per
string string
2 2
2, fully independent 2, fully independent
4-pole, 600 V, 15 A 4-pole, 600 V, 15 A
100-600 Vdc per string
180-480 Vdc per string 140-480 Vdc per string 220-480 Vdc per string
MC4
94% (93% EU)
99.9%
PR50S PR37S
o o
-10 C to +50 C (derating to prevent overtemperature)
o o
-40 C to +70 C
maximum 95%, non-condensing
CE, VDE-AR-N 4105:2011-08, EEG2012, C-Tick
EN 60950-1, EN 62109-1-2
EN 61000-3-2, EN 61000-3-3, EN 61000-6-3, EN 61000-3-12
EN 61000-6-2, EN 61000-3-11
VDE 0126.1.1, G83/1(UK), RD1699/2011(ESP), CEI0-21 (IT), AS4777
(AUS)
(check www.PowerRouter.com for other country certifications)
five years (optional: extension to ten years)
PR30S
3000 W
15 A
PR30S
3.3 kWp total, 15 A
1
1
2-pole, 600 V, 15 A
PR30S
