PowerRouter • Solar Inverter • Installation manual
1
2
i
Read the installation
manual for details
A
!
A
A min. 300 mm
B
min. 800 mm
Drill template the PowerRouter
Installation
steps
1
Drill template for the PowerRouter
A
B
A
Drill template the PowerRouter
4 x
2 4 x
*A31100011*
the PowerRouter
mounting bracket
370 mm max. ø 5.5 mm
400 mm max. ø 10 mm
2 x
3 4
470 mm max. ø 5.5 mm
Illustrations
+
Max.40°C
15 KG
Min.-10°C
2 x
5 6
Partno. 5555477,1
