Hardware Overview

Bottom View

Technology
Reset Button
Reset button for more than 10 seconds while the PowerBeam
is already powered on. Alternatively, the PowerBeam may be
reset remotely via a Reset button located on the bottom of the
Gigabit PoE Adapter.
Release Button
the Release button; it should be fully engaged in the Release
Button Slot of the Rear Housing. This ensures that the Antenna
Feed is locked into place. If you need to remove the Antenna
Feed, you must depress the Release button first.
To reset to factory defaults, press and hold the
After you assemble the PowerBeam, check
Antenna Feed
Ethernet Port
Reset Button
Release Button
Dish
Reflector
Mounting Bracket
Alignment Pins
Rear Housing
Release
Button Slot
Cable Door
