- Page 1 High-Performance airMAX Bridge ™ Models: NB-2G18-HP, NB-5G25-HP...
-
Page 3: Package Contents
Introduction Introduction Thank you for purchasing the Ubiquiti Networks NanoBridge ™ ™ This Quick Start Guide is designed to guide you through the installation of the NanoBridge and show you how to access the airOS Configuration Interface. This Quick Start Guide is ™... -
Page 4: Installation Requirements
Ethernet connections and should be grounded through the AC ground of the PoE. We recommend that you protect your networks from the most brutal environments and devastating ESD attacks with industrial-grade shielded Ethernet cable from Ubiquiti Networks. For more details, visit www.ubnt.com/toughcable... -
Page 5: Installation
Installation Installation The installation instructions show the NanoBridgeM2HP; however, the same instructions apply to the NanoBridgeM5HP. 1. Line up the three tabs of the Dish Bracket to the three slots of the Dish Reflector using the orientation shown below. Insert the tabs and rotate the Dish Bracket until the tabs lock into place. - Page 6 NanoBridge M2/M5HP Quick Start Guide ™ 3. Insert the Antenna Feed into the Rear Housing using the orientation shown below and push until it locks into place. 4. Connect the Ethernet cable by performing the following steps: a. Push in the tabs of the cable door and detach it from the Rear Housing.
- Page 7 Installation 5. Slide the Pole Clamp onto the Dish Bracket. 6. Insert the M8 U-Bolt into the Pole Clamp and Dish Bracket. Secure the M8 U-Bolt with two M8 Locknuts. Note: The mounting assembly can accommodate a Ø 1.25" - 2.2" pole.
- Page 8 NanoBridge M2/M5HP Quick Start Guide ™ 7. Connect the other end of the Ethernet cable from the NanoBridge to the Ethernet port labeled POE on the PoE Adapter. 8. Connect an Ethernet cable from your LAN or computer to the Ethernet port labeled LAN on the PoE Adapter. 9.
- Page 9 Accessing airOS Accessing airOS Verify connectivity in the airOS Configuration Interface. 1. Make sure that your host machine is connected via Ethernet to the NanoBridge. 2. Configure the Ethernet adapter on your host system with a static IP address on the 192.168.1.x subnet. 3.
-
Page 10: Installer Compliance Responsibility
Since Ubiquiti Networks equipment can be paired with a variety of antennas and cables, the Output Power field is provided to the professional installer to assist in meeting regulatory requirements. -
Page 11: Specifications
Specifications Specifications NanoBridge Dimensions NanoBridgeM2HP 420 x 420 x 289 mm (Mount Included) NanoBridgeM5HP 420 x 420 x 275 mm (Mount Included) Weight NanoBridgeM2HP 1.814 kg NanoBridgeM5HP 1.775 kg Operating Frequency NanoBridgeM2HP 2405 - 2475 MHz US: 5255 - 5340 MHz NanoBridgeM5HP 5475 - 5595 MHz 5655 - 5715 MHz... -
Page 12: Safety Notices
Products furnished hereunder shall be free from defects in material and workmanship for a period of one (1) year from the date of shipment by UBIQUITI NETWORKS under normal use and operation. UBIQUITI NETWORKS sole and exclusive obligation under the foregoing warranty shall be to repair or replace, at its option, any defective Product that fails during the warranty period. -
Page 13: Warranty Conditions
Buyer for breach of warranty and shall constitute fulfillment of all liabilities of UBIQUITI NETWORKS with respect to the quality and performance of the Products. UBIQUITI NETWORKS reserves the right to inspect all defective Products (which must be returned by Buyer to UBIQUITI NETWORKS factory freight prepaid). -
Page 14: Industry Canada
NanoBridge M2/M5HP Quick Start Guide ™ Compliance Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. -
Page 15: Rf Exposure Warning
Compliance Cet appareil est conforme à la norme RSS Industrie Canada exempts de licence norme(s). Son fonctionnement est soumis aux deux conditions suivantes: 1. Cet appareil ne peut pas provoquer d’interférences et 2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement du dispositif. - Page 16 NanoBridge M2/M5HP Quick Start Guide ™ Deutsch Die Europäische Richtlinie 2002/96/EC verlangt, dass technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeindeabfall entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt von regulärem Haushaltmüll getrennt entsorgt werden sollte.
-
Page 17: Declaration Of Conformity
Declaration of Conformity Česky UBIQUITI NETWORKS tímto prohla uje, e tento UBIQUITI NETWORKS device, je ve shod se základními po adavky a dal ími p [Czech] íslu n mi ustanoveními sm rnice 1999/5/ES. - Page 18 UBIQUITI NETWORKS device, megfelel a vonatkozó alapvetõ [Hungarian] követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. Íslenska Hér me l sir UBIQUITI NETWORKS yfir ví a UBIQUITI NETWORKS device, er í samræmi vi grunnkröfur og a rar kröfur, sem ger ar eru í [Icelandic] tilskipun 1999/5/EC.
-
Page 20: Ubiquiti Networks Support
Email: support@ubnt.com Phone (9 a.m. - 5 p.m. PST): 408-942-1153 Online Resources Wiki Page: wiki.ubnt.com Support Forum: forum.ubnt.com Downloads: downloads.ubnt.com w w w . u b n t . c o m © 2012 Ubiquiti Networks, Inc. All rights reserved.
