20" Production drill Press
asseMbly & oPerating instructions
read this material before using this product.
Failure to do so can result in serious injury.
saVe this Manual.
Copyright
1999 by Harbor Freight Tools
©
tained herein may be reproduced in any shape or form without the express written consent of Harbor Freight
Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual
product may differ slightly from the product described herein. Tools required for assembly and service may not
be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 03c, 09l
Model
Visit our website at: http://www.harborfreight.com
. All rights reserved. No portion of this manual or any artwork con-
®
39955

Advertisement

loading
Need help?

Need help?

Do you have a question about the 39955 and is the answer not in the manual?

Questions and answers

Related Manuals for Central Machinery 39955

Summary of Contents for Central Machinery 39955

  • Page 1 20” Production drill Press Model 39955 asseMbly & oPerating instructions Visit our website at: http://www.harborfreight.com read this material before using this product. Failure to do so can result in serious injury. saVe this Manual. Copyright 1999 by Harbor Freight Tools .
  • Page 2 Wear a full face shield if your are producing metal or wood filings. Do not reach over or across running machines. Maintain proper footing and balance at all times. REV 05l SKU 39955 For technical questions, please call 1-800-444-3353. Page 2...
  • Page 3 Use an adapter and always connect the grounding plug to a known grounding source. It is recommended that you have a qualified electrician replace the two-prong outlet with a properly grounded three- prong outlet. SKU 39955 For technical questions, please call 1-800-444-3353.
  • Page 4 Unpacking Unpack and check contents. Make sure you have all parts described below. If any parts are missing or broken, please call Harbor Freight Tools at 1-800-444-3353. REV 03c,08l SKU 39955 For technical questions, please call 1-800-444-3353. Page 4...

  • Page 5: Extension Cords

    Hex Socket grub Screws (part #7B). It may be necessary to unscrew the Hex Socket Screws (part #7B) slightly to ensure that they do not protrude internally, as this will prevent the Column from sliding fully into position in the Tube. SKU 39955 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6 Step 8) Check the Column Collar for proper adjustment. The Collar should sit evenly on the Column and the Rack should slide freely when the Table is rotated 360 degrees. SKU 39955 For technical questions, please call 1-800-444-3353. Page 6...
  • Page 7 Oiler System Step 1) Use four M5x0.8-8 Screws (#51A) to fasten the two Oil Brackets (#50A). Insert the Oil Bottle with Spigot Assembly (#52A and #53A) into the Oil Brackets. SKU 39955 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 Light Bulb Screw a light bulb (not more than 60 Watt) into the Socket (part #48A) inside the Head. REV 03c SKU 39955 For technical questions, please call 1-800-444-3353. Page 8...

  • Page 9: Operation

    1/2” at their centers of run when using rea- sonable thumb pressure. Lock the motor in this position with the Locking Knob. 1180 1565 2190 3865 1805 2795 SKU 39955 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10 Lock the Collar in position using the Locking Screw. The Drill is now set to drill holes to your predetermined depth from that particular starting point. Figure 3 REV 03c SKU 39955 For technical questions, please call 1-800-444-3353. Page 10...
  • Page 11 Generally, the SMALLER THE DRILL BIT the GREATER THE REQUIRED RPM. In soft material, the speed should be higher than for hard metals. As a guide, the drill speed for a given drill bit size is listed in the chart below. REV 03c SKU 39955 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12 Child-proof the machine and work area. Make sure to use padlocks, master switches and remove the safety Lock Key. if there is any question about a condition being safe or unsafe do not operate the tool SKU 39955 For technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Please Read The Following Carefully

    ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 39955 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14 Foam Washer Chuck Pulley Cover Arbor Retaining Ring Spindle Ball Bearing Ball Bearing- 30mm Bearing Spacer Insert-Pulley Spindle Pulley Parts List - #39955 A Part # Description Quantity Part # Description Quantity Screw-Hex Head M8 . Screw Adjusting Lever Switch Box Motor Bracket Support Screw-Pan Cr.
  • Page 15 Assembly Diagram - #39955 REV 05j SKU 39955 For technical questions, please call 1-800-444-3353. Page 15...
  • Page 16 Assembly Diagram - #39955 A Note: All part numbers shown in this diagram have an “A” suffix. REV 03c; 08l SKU 39955 For technical questions, please call 1-800-444-3353. Page 16...
  • Page 17 Table w/Scale Rack Pin - Gear Screw-hex Soc Set Column Clamp Column Support Helical Gear Screw Worm- Elevation Base Note: All part numbers shown in this diagram have a “B” suffix. SKU 39955 For technical questions, please call 1-800-444-3353. Page 17...
  • Page 18 SKU 39955 For technical questions, please call 1-800-444-3353. Page 18...

  • Page 19: Limited 1 Year / 90 Day Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 REV 08l SKU 39955 For technical questions, please call 1-800-444-3353. Page 19...
