In compliance with
47 CFR 15 Subpart B
CAN RSS-Gen/CNR-Gen
5-pin option models:
● MPR30-ENG-5PW: through the power supply V+= 5V (pin 4 of mini XLR), the battery is charged (if you insert a
rechargeable lithium-ion battery). We advisable not to use the receiver while charging the battery.
● MPR30-ENG-5BY: through the power supply V+= 5V (pin 4 of mini XLR), the receiver is powered but is not
charged the battery (the battery operates only when power is removed).
Maximum power= 6Vdc (5.5V recommended)
M
ECHANICAL
91
27
Note: unit is mm
D
RAWING
65.4
69
MPR30-ENG User Manual
Rev. 14
91
29
