Rev. 14
MPR30-ENG User Manual
Instruction to connect MPR30 using USB cable:
In order to use the micro USB port to configure the
MPR30, it is necessary to install the MPR30 USB
driver (see How to install MPR30 USB driver)
1.
Connect the MPR30 to the PC through the
micro USB interface using the USB cable
2.
Check if the version of ENG RX Manager
installed in your PC is the latest version. If
not, uninstall the ENG RX Manager actives
in your PC and install the new version
3.
Run ENG RX Manager
4.
Power up the receiver MPR30
5.
Push Disconnected button. On the Device
6.
If the connection is ended
well, the Connected icon
is showed on the top of
the panel and "Connected
on COMx" is displayed on
the information panel
26
connection windows select USB port
and verify that a COMx is selected
on the Virtual COM panel. If COMx is
not showed, push Refresh button
and/or try to disconnect and
reconnect the USB cable connected
to the MPR30. Then click OK.
