Rev. 14
MPR30-ENG User Manual
Edit RX menu > Cal.Tone submenu
Settings menu
Settings menu > Name submenu
Settings menu > Display submenu
18
Calibration Tone function generates a 1 KHz sine audio at
the audio outputs (LINE and headphone) at the level
selected (-18dB or 0dB). Select the level and push SEL Button
to start calibration tone function. Then push EXIT button to
stop it.
The Settings menu allows to configure main settings of the
device.
The name menu allows to change the name of the receiver.
This is the name displayed in the top of the Status display
and it is the name sent to the transmitter with the sync
function (for the transmitter with this advanced capability).
Use the UP/DOWN buttons to change the selected character
and push SEL button to switch to the next character.
Change contrast display from 0 (min) to 5 (max).
Low timeout sets the timeout from 5 to 60 seconds to
decrease the brightness display.
Off timeout sets the timeout from 10 to 120 seconds to turn
off the display. With OFF setting the display never turns off.
