MPR30-ENG User Manual
Info menu
PARAMETER MEANING
Model Wisycom receiver model
Range Frequencies range of working
Serial Serial number
Version *
BL
FW
App
DSP
Version
HW
Option
Battery Batteries voltage
Number of errors.
If the number of errors is > 0 push SEL button to enter on the Errors
Errors
list. For each error a brief description and the error code is showed.
For more information, please see the
* The Firmware Version recaps BL (Bootloader Version) and App (Application version).

Preset menu

Preset submenu
20
The INFO function shows many important features or information of
MPR30 receiver:
Firmware version
Bootloader version
Application version
DSP version
Hardware version
MPR30-ENG Options
N= freq. range 470 ÷ 700 MHz,
M= freq. range 566 ÷ 798 MHz
J= freq. range 712 ÷ 832 MHz
This menu allows to load/save 3 user presets or load the
Factory configuration.
Select the Restore submenu and chose the presets to load:
user presets (1 or 2 or 3) or Factory preset. Push and keep
SEL button to load the preset.
Select the Save submenu and chose the user presets to
save (1 or 2 or 3). Push and keep SEL button to save the
preset.
Error List section.
example
MPR30-ENG
566-798
S1733185
v1.09
v1.1d
v0.64d
v0.14d
6
M
2.68 Volt
0
