Led Indicators - OWC Mercury Elite Pro Dual mini Assembly Manual & User Manual

Pro Dual mini does not support bus-powering other devices.
2. USB 3.0 port — Attach the included USB 3.0 (Standard-A to Micro-B) cable here.
3. On/off switch — Turn on and off the Mercury Elite Pro Dual mini here.
4. Power input — Connect the 12V power adapter here (sold separately).
NOTE:
• When connected using FireWire, the Mercury Elite Pro Dual mini will receive all
necessary power from the computer through the FireWire port. However, the USB
connection does not provide as much power as FireWire. When connecting over
USB, an external power adapter is required. The 12V power adapter is available at:
http://eshop.macsales.com/item/OWC/MEP2BAYM15/
• If the Mercury Elite Pro Dual mini is daisy-chained off of another FireWire device
instead of being connected directly to a computer, you must use the 12V power
adapter. Attempting to bus-power the Mercury Elite Pro Dual mini using the FireWire
port of another device could cause damage to one or both devices and should not
be attempted.
• Even when the power 12V power adapter is not connected, the on/off switch must
be in the 'on' position in order to use the Mercury Elite Pro Dual mini.
• Only one interface (USB or FireWire) at a time can be used.
• For the safe removal of your drive and to ensure that no data is lost, always eject or
unmount the drive from your operating system before powering off.

1.5 LED INDICATORS

The Mercury Elite Pro Dual mini has two multicolored LED indicators located behind the
front grill, one for each drive. The following chart shows how to interpret the activity of
these LED indicators.
NORMAL
OPERATION
SOLID BLUE FOR
DRIVE 1
POWER,
LED
BLUE FOR ACTIVITY
SOLID BLUE FOR
DRIVE 2
POWER,
LED
BLUE FOR ACTIVITY
NOTE: In the event of a failure and rebuild of drive 2, simply switch the rows for "Drive 1
LED" and "Drive 2 LED".
OWC MERCURY ELITE PRO DUAL MINI
DRIVE 1 FAILURE
SOLID RED
FLASHING
SOLID BLUE FOR
POWER,
FLASHING
BLUE FOR ACTIVITY
DRIVE 1 REBUILD
STEADY BLINKING
RED FOR REBUILD,
FLASHING BLUE
FOR ACTIVITY
SOLID BLUE FOR
POWER,
FLASHING
BLUE FOR ACTIVITY
2
DOUBLE
FAILURE
SOLID
RED
SOLID
FLASHING
RED
INTRODUCTION
