Protection against Entrapment

Important! Study the figure below and keep safety foremost at all times.
Entrapment areas for a proper pull-to-open installation
Entrapment Area 1
Hinged edge of the gate and the fence post
Entrapment Area 2
Between the gate and the gate post
Entrapment Area 3
The path of the gate
Entrapment Area 4
The space between the gate in the open position and
any object such as a wall, fence, tree, etc.
Entrapment Area 5
Pinch points between the operator and gate or post
Area 5
Area 4
Gate in open
position
Area 1
Area 3
Driveway
Area 2
