Page 1: User Manual
User manual NIBE™ F2030 Air/water heat pump UHB GB 1317-1 231116... -
Page 3: Table Of Contents
1 Important information Installation data Safety information Safety precautions Serial number Contact information F2030 - An excellent choice 2 The heat pump – the heart of the house Heat pump function Contact with F2030 Maintenance of F2030 3 Disturbances in comfort... -
Page 4: Important Information
Installation data Product F2030 Serial number Installation date Installer Serial number must always be given Certification that the installation is carried out according to instructions in NIBE's installer manual and applicable regulations. Date __________________ Signed _________________________ ✔ Chan- Name Default... -
Page 5: Nibe™ F2030
✔ Chan- Name Default Accessories set- tings Min. interval between defrosting Start defrosting -3 °C Stop defrosting +20 °C Activation collar heat- Activation de-icing fan Defrosting type Chapter 1 | Important information NIBE™ F2030... -
Page 6: Safety Information
Children should be supervised to ensure that they do not play with the appliance. This is an original instruction manual. Translation is not allowed without approval from NIBE. Rights to make any design or technical modifications are reserved. ©NIBE 2013. -
Page 7: Safety Precautions
Marking The CE marking means that NIBE ensures that the product meets all regu- lations that are placed on it based on relevant EU directives. The CE mark is obligatory for most products sold in the EU, regardless where they are made. - Page 8 Wait at least 5 minutes, otherwise there is a risk of water leakage or breakdown. Do not control the system with the main switch. This can cause fire or water leakage. In addition, the fan can start unexpectedly, which can cause personal injury. Chapter 1 | Important information NIBE™ F2030...
-
Page 9: Serial Number
Serial number The serial number can be found at the top left of the rear cover and on the foot of the product. Caution Always give the product's serial number when reporting a fault. Chapter 1 | Important information NIBE™ F2030... -
Page 10: Contact Information
Puh: 09-274 697 0 Fax: 09-274 697 40 E-mail: info@nibe.fi www.nibe.fi AIT France, 10 rue des Moines, 67000 Haguenau Tel : 03 88 06 24 10 Fax : 03 88 06 90 15 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk... - Page 11 NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46-(0)433-73 000 Fax: +46-(0)433-73 190 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information. Chapter 1 | Important information...
-
Page 12: F2030 - An Excellent Choice
-25°C. Intelligent control Integrated intelligent control for optimum control of the heat pump. At a start signal from an NIBE indoor module or thermostat F2030 is started. F2030 has an automatic 2-step capacity regulator for the fan. Long service life The material has been chosen for a long service life and is designed to withstand the Nordic outdoor conditions. -
Page 13: The Heat Pump - The Heart Of The House
Expansionsventil Kompressor Förångare 0 °C 5 °C -3 °C 2 °C The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2030... - Page 14 The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2030...
-
Page 15: Contact With F2030
Contact with F2030 F2030 has an integrated control system that checks and monitors the heat pump operation. At installation the installer makes the necessary settings of the control system so that the heat pump will work optimally in your system. -
Page 16: Maintenance Of F2030
When your heat pump is located outdoors some external maintenance is required. NOTE Insufficient oversight can cause serious damage to F2030 which is not covered by the guarantee. Checking grilles Check that the inlet grille is not clogged by leaves, snow or anything else regularly throughout the year. -
Page 17: In Event Of Long Power Cuts
Care must be exercised so that the heat pump is not scratched when cleaning. Avoid spraying water into the grilles or the sides so that water penetrates into F2030. Prevent F2030 coming into contact with alkaline cleaning agents. Condensation drain pan and condensation water pipe The trough and drain pipe may require cleaning from leaves or similar during the year. -
Page 18: Saving Tips
In the past it has been calculated that an average Swedish household has an approximate annual consumption of 5000 kWh domestic electri- city/year. In today's society it is usually between 6000-12.000 kWh/year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2030... - Page 19 WC, 2 bulbs in the bathroom, 4 bulbs in the kitchen, 3 bulbs outside, a washing machine, tumble drier, fridge, freezer, oven, vacuum cleaner, engine block heater = 6240 kWh domestic electricity/year. Chapter 2 | The heat pump – the heart of the house NIBE™ F2030...
- Page 20 After 1-2 years the heating curve should be adjusted again, as well as the heating curve offset and the building's thermostat valves, because the heating system, as a rule, requires a lower temperature once the drying process is complete. Chapter 2 | The heat pump – the heart of the house NIBE™ F2030...
-
Page 21: Disturbances In Comfort
The following tips can be used to rectify comfort disruption: Basic actions Start by checking the following possible fault sources: That the heat pump is running or that the supply cable to F2030 is connected. Group and main fuses of the accommodation. -
Page 22: Low Room Temperature
Set the thermostats to max in as many rooms as possible. External switch for changing the room heating activated. Check any external switches. Incorrect settings in NIBE SMO or NIBE indoor module See the manual for the indoor module. High room temperature External switch for changing the room heating activated. - Page 23 Ice build up on the fan blades and front grille Contact your installer! Chapter 3 | Disturbances in comfort NIBE™ F2030...
-
Page 24: Technical Data
4 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (www.nibe.eu). Chapter 4 | Technical data NIBE™ F2030... -
Page 25: Glossary
Charge coil A charge coil heats the domestic hot water (tap water) in the heater with heating water from F2030. Charge pump See "Circulation pump". Circulation pump Pump that circulates liquid in a pipe system. -
Page 26: Domestic Hot Water
Efficiency A measurement of how effective the heat pump is. The higher the value is the better it is. Chapter 5 | Glossary NIBE™ F2030... -
Page 27: Expansion Valve
Hot liquid, usually normal water, which is sent from the heat pump to the house climate system and makes the accommodation warm. The heating medium also heats the hot water. Heating medium side Pipes to the house’s climate system make up the heating medium side. Chapter 5 | Glossary NIBE™ F2030... -
Page 28: Safety Valve
Radiator Another word for heating element. They must be filled with water in order to be used with F2030. Refrigerant Substance that circulates around a closed circuit in the heat pump and that, through pressure changes, evaporates and condenses. During evap- oration, the refrigerant absorbs heating energy and during condensing, gives off heating energy. - Page 29 Supply temperature The temperature of the heated water sent by the heat pump to the heating system. Chapter 5 | Glossary NIBE™ F2030...
-
Page 30: Item Register
In event of long power cuts, 15 Regular checks, 14 Disturbances in comfort Saving tips, 16 Troubleshooting, 19 Power consumption , 16 F2030 – An excellent choice, 10 Regular checks, 14 Glossary, 23 Safety precautions, 5 Heat pump function, 12 Saving tips, 16... - Page 32 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231116...
