Diamond DA20-C1 Maintenance Manual page 81

DA20-C1 AMM
1. General
The following maintenance practices describe how to remove and install the elevator. Refer to Chapter
27-30 for adjustment data for the elevator control system.
2. Remove/Install the Elevator
A. Remove the Elevator
NOTE: Use 2 persons to remove/install the elevator. Or use control clamps to hold the elevator in
position while you remove/install the attaching bolts.
1. Remove the horizontal stabilizer fairing.
- Remove the four screws.
2. Remove the bolt that connects the elevator
vertical control rod to the elevator horn.
3. Remove the five elevator hinge bolts.
5. Lift the elevator clear of the aircraft.
B. Install the Elevator
1. Put the elevator in position on the horizontal
stabilizer.
2. Install the five hinge bolts.
3. Install the bolt which connects the elevator
vertical control rod to the elevator horn.
DA201-C1
Rev 16
ELEVATOR - MAINTENANCE PRACTICES
Detail Steps/Work Items
Detail Steps/Work Items
55-20-00
Key Items/References
Hold the elevator.
There are two bolts outboard at each side
and one center bolt through the control
horn.
Key Items/References
Use 2 persons.
There are two bolts outboard at each side
and one center bolt through the control
horn.
Refer to Chapter 20 for standard torque
values.
Make sure that the fork of the elevator trim
actuator engages the spring mount on the
control rod.
Maintenance Practices
Page 201
30 Oct 09
