Checklist für Diamond DA40 TDI Diamond Star
Edition #: 17.1 Edition date: 15.04.2017
Please observe:
The file you are receiving hereby combines all three sections of the checklist: Normal
Checklist, Emergency Checklist and Abnormal Checklist.
All pages of a new edition will have the same new "edition #" and "edition date", even if
only one page was amended and all other pages still have the same, unchanged content.
Therefore the "List of Effective Pages" (LEP) is provided. It is here where you can see
whether a particular page was amended. Pages which have been amended by a new
edition will be marked yellow. For all other pages you will see which original "edition #"
(and of course any higher "edition #") is still valid.
Note:
The system of assigning "Edition #" is as follows:
•
if the revision affects all types, a new edition # (without a decimal figure) will be
assigned to all of the checklists
•
if the revision does not affect all types, the affected checklists will get subsequent
"decimal figures" until a major revision affecting all checklists is issued.
Have a lot of nice flights and happy landings!
Peter Schmidleitner
Comments explaining Edition # 17.1 are on page 2 of this document
Checklist DA40 TDI - LEP
Page
Edition
(or any higher)
Section : Normal Checklist
1
14
2
15.2
3
14
4
17.1
5
14
6
14
7
14
8
15.2
Following
Date
is valid
01.12.2006
01.03.2015
01.12.2006
15.04.2017
01.12.2006
01.12.2006
01.12.2006
01.03.2015
Section: Emergency Checklist
1
15.1
2
15.1
3
15
4
15
5
15
6
15
Section: Abnormal Checklist
7
14
8
14
9
14
10
14
20.03.2014
20.03.2014
20.05.2010
20.05.2010
20.05.2010
20.05.2010
01.12.2006
01.12.2006
01.12.2006
01.12.2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the Diamond Star DA40 TDI and is the answer not in the manual?

Questions and answers

Related Manuals for Diamond Diamond Star DA40 TDI

Summary of Contents for Diamond Diamond Star DA40 TDI

  • Page 1 Checklist für Diamond DA40 TDI Diamond Star Edition #: 17.1 Edition date: 15.04.2017 Please observe: The file you are receiving hereby combines all three sections of the checklist: Normal Checklist, Emergency Checklist and Abnormal Checklist. All pages of a new edition will have the same new “edition #” and “edition date”, even if only one page was amended and all other pages still have the same, unchanged content.
  • Page 2 Comments explaining Edition # 15.1 Emergency Checklist: Page 1: “Emergency Landing”: Safety harnesses added Page 2: “Rough Engine and/or Power Loss” updated Comments explaining Edition # 17 Preflight Procedures: Page 2: Parking brake, chocks, towbar added Normal Procedures: Page 8: Parking Check, item 3: Text of ELT check revised Comments explaining Edition # 17.1...
  • Page 3 Airplane Flight Manual. Use of the checklist is at the user's sole risk and discretion. Any possible liability of Diamond Flight Training and/or Diamond Aircraft for any damages, injury or death resulting from its use is excluded.
  • Page 4 Drain fuel strainer security) Wing flap Left fuselage Chocks removed Canopy left side Towbar removed Rear door Fuselage left side Antennas 15.04.2017 Diamond Flight Training Page 2 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 5 Fuel quantity........CHECKED 30 Fuel temperature ......CHECKED 31 Hobbs meter ........NOTED 32 Power lever........... IDLE 33 ACL (strobe) ........... ON 34 End of Checklist 15.04.2017 Diamond Flight Training Page 3 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 6 Horizon / Directional gyro ..CHECKED / SET 13 Transponder ....CODE / MODE CHECKED 14 Parking brake........ RELEASED 15 End of Checklist DURING TAXI Check Brakes Check flight instruments 15.04.2017 Diamond Flight Training Page 4 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 7 Pitot heat ........ AS REQUIRED 16 Transponder ....CODE / MODE CHECKED 17 Parking brake........ RELEASED 18 End of Checklist For procedural items and take-off profile see next page 15.04.2017 Diamond Flight Training Page 5 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 8 ....CHECK RPM /OP / LOAD / Fuel flow Rotate at 59 kt AFTER TAKE-OFF PROCEDURE After passing safe altitude: Flaps ............UP Landing light..........OFF 15.04.2017 Diamond Flight Training Page 6 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 9 Flaps ............T/O Landing light..........ON On final: Flaps ............LDG GO AROUND PROCEDURE Power ............MAX Flaps ............T/O Continue with take-off profile 15.04.2017 Diamond Flight Training Page 7 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 10 Never exceed speed (V Manoeuvring speed (V <-980kg-> Max. turbulence speed Weights Empty weight 850 kg Max. TKOF weight 1150 kg Max. baggage weight 30 kg 15.04.2017 Diamond Flight Training Page 8 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 11 3 Emergency fuel valve....... OFF 4 Engine Master ......... OFF On final: 5 Flaps .............LDG 6 Safety harnesses........TIGHT 7 Electric master switch ......OFF 15.04.2017 Diamond Flight Training Page 1 Edition # 11 Does not replace the Airplane Flight Manual...
  • Page 12 In case of power loss: ECU reset: 9 Engine master......... OFF – ON If no success: 10 ECU swap..........AUTO 10 If no success and insufficient power: Land ASAP 15.04.2017 Diamond Flight Training Page 2 Edition # 11 Does not replace the Airplane Flight Manual...
  • Page 13 1 Emergency fuel valve..EMERG. TRANSFER 2 AUX fuel quantity ....CHECK min 1 USG 3 MAIN fuel quantity.....CHECK max 15 USG 4 Emergency fuel valve..... reset to NORMAL 15.04.2017 Diamond Flight Training Page 3 Edition # 11 Does not replace the Airplane Flight Manual...
  • Page 14 9 Power lever .... ADJUST to max. 2300 RPM RPM UNDERSPEED 1 Power lever ......AS REQUIRED 2 ECU swap..........ECU B • If no success: 3 ECU swap..........AUTO Land ASAP 15.04.2017 Diamond Flight Training Page 4 Edition # 11 Does not replace the Airplane Flight Manual...

  • Page 15: Engine Fire In Flight

    7 Emergency fuel valve....... OFF 8 Power lever ........... MAX 9 Engine Master ......... OFF On final: 10 Flaps .............LDG 10 11 Electric master switch ......OFF 11 15.04.2017 Diamond Flight Training Page 5 Edition # 11 Does not replace the Airplane Flight Manual...
  • Page 16 3 Emergency switch ........ON 4 Flood light, if necessary......ON 5 Power ............ SET according power lever position and/or engine noise 6 Flaps ........VERIFY POSITION Land ASAP 15.04.2017 Diamond Flight Training Page 6 Edition # 11 Does not replace the Airplane Flight Manual...
  • Page 17 LH TANK FUEL QTY LOW Fuel transfer pump: ON Check fuel quantity If light still ON: ⇒ Expect fuel leak ⇒ Be prepared for emergency landing 15.04.2017 Diamond Flight Training Page 7 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 18 If all CBs OK: ⇒ ESSENTIAL BUS: ON Switch off unnecessary electrical equipment Land ASAP Be prepared for engine fail; be prepared for emergency landing 15.04.2017 Diamond Flight Training Page 8 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 19 Increase airspeed Oil temperature (OT) low Increase power Reduce airspeed Fuel temperature high Reduce power Increase airspeed Fuel temperature low Increase power Reduce airspeed 15.04.2017 Diamond Flight Training Page 9 Edition # 17.1 Does not replace the Airplane Flight Manual...
  • Page 20 Land ASAP VOLT low Check circuit breakers Switch off unnecessary electrical equipment If light still ON ⇒ Apply “ALTERNATOR”-caution procedure VOLT high Land ASAP 15.04.2017 Diamond Flight Training Page 10 Edition # 17.1 Does not replace the Airplane Flight Manual...
