Diamond DA20-C1 Maintenance Manual page 75

DA20-C1 AMM
HORIZONTAL STABILIZER - MAINTENANCE PRACTICES
1. General
The following maintenance practices describe how to remove and install the horizontal stabilizer.
2. Remove/Install the Horizontal Stabilizer
Refer to Figure 201.
A. Remove the Horizontal Stabilizer
NOTE: Use 2 persons to remove/install the horizontal stabilizer.
1. Remove the horizontal stabilizer fairing.
- Remove the four screws.
2. Remove the bolt that connects the elevator
vertical control rod to the elevator horn.
3. Remove the two bolts that connect the lower
mounting bracket to the upper mounting
bracket.
4. Remove the four bolts that attach the
horizontal stabilizer mount plate to the vertical
stabilizer.
5. Lift the horizontal stabilizer clear of the aircraft.
DA201-C1
Rev 17
Detail Steps/Work Items
55-10-00
Key Items/References
Hold the horizontal stabilizer.
Use 2 persons.
Maintenance Practices
Page 201
01 Nov 10
