I. Rollbar
The rollbar is a rigid GFRP molding. Carbon tape gives strength and stiffness to the rollbar. The
rollbar bonds to the inner face of the fuselage shell around the rear cockpit cut-out.
J. Aft Control Bulkhead
The aft control bulkhead is a rigid GFRP molding. The middle part has top and bottom flanges
which hold the control bellcranks. The bulkhead bonds to the aft face of the spar bridge. It also
bonds to the fuselage shell.
K. B-bulkhead
The B-bulkhead is a large rigid GFRP molding. The main part of the bulkhead has a slope of about
45°. The middle of the bulkhead makes a box for the fuel tank. The top part has a box for the
battery.
L. Half bulkhead
The half bulkhead is a rigid GFRP molding. It bonds to the bottom of the fuselage shell just aft of
the B-bulkhead. It has a guide bearing for the elevator control pushrod and holes for the rudder
control cables. It has a cut-out on the right side for a cable conduit.
M. Ring-Bulkhead #1
The ring bulkhead #1 is a rigid GFRP molding. It bonds to the fuselage shell just aft of the half
bulkhead. It has holes for the elevator control pushrod and the rudder control cables. It has a cut-
out on the right side for a cable conduit.
N. Ring-Bulkhead #2
The ring bulkhead #2 is a rigid GFRP molding. It bonds to the fuselage shell half way along the rear
fuselage. It has a guide bearing for the elevator control pushrod and holes for the rudder control
cables. It has a cut-out on the right side for a cable conduit.
O. Ring-Bulkhead #3
The ring bulkhead #3 is a rigid GFRP molding. It bonds to the fuselage shell just forward of the
vertical stabilizer. It has holes for the elevator control pushrod and the rudder control cables. It has
a cut-out on the right side for a cable conduit.
P. Ring-Bulkhead #4
The ring bulkhead #4 is a rigid GFRP molding. It bonds to the fuselage shell below the vertical
stabilizer. It has a very large cut-out for the elevator control pushrod, the rudder control cables and
a cable conduit.
Q. Vertical Stabilizer Lower Rib
The vertical stabilizer lower rib is a rigid GFRP molding. It bonds to the fuselage shell at the bottom
of the vertical stabilizer. It also bonds to the spar, vertical stabilizer. It has a large slot for the
elevator control pushrod. It has a mount for the VHF antenna at the front.
