Maintenance Practices
B. Install the Sliding Side Window
1. Assemble the sliding window as follows:
- Install the sliding window knob into the
sliding window
- Install the hinge block using two screws.
2. Install the sliding window with the guide rails.
3. Secure the guide rails with eight nylon screws.
4. If the sliding window installed does not include
the clear/tinted sliding window air scoop and
the air scoop lock, install as follows:
- Install the hinge with the screw, the
washer, and the nut
- Install the clear/tinted sliding window air
scoop
- Install the air scoop lock with the screw,
the nut, the two thin washers, and a nylon
washer.
Page 206
30 Oct 09
Detail Steps/Work Items
52-10-00
Key Items/References
Refer to Figure 203.
