DA20-C1 AMM
1.

General

The following maintenance practices describe how to remove and install the canopy and how to do a
canopy latch force test/adjustment.
2.

Remove/Install the Canopy

CAUTION: TWO PEOPLE WILL BE NEEDED TO REMOVE/INSTALL THE CANOPY. THE
CANOPY WILL BE DAMAGED IF YOU DROP IT.
A. Remove the Canopy
1. Open the canopy.
2. Remove the screws that attach the rear hinge
to the rear of the canopy.
3. Remove the rod end bearings from the
stabilizing rods at the canopy frame.
4. Lift the canopy clear of the aircraft.
B. Install the Canopy
1. Lift the canopy into position on the aircraft. And
hold the canopy open.
2. Install the rod end bearings to the stabilizing
rods at the canopy frame.
3. Install the screws that attach the hinged tube to
the rear of the canopy.
4. Close the canopy and operate both canopy
latches.
5. Set the GEN/BAT switch to ON.
DA201-C1
Rev 16

CANOPY - MAINTENANCE PRACTICES

Detail Steps/Work Items
Detail Steps/Work Items
52-10-00
Key Items/References
Hold the canopy.
Key Items/References
Make sure the canopy latch mechanism
pulls the canopy fully closed.
Make sure the canopy warning light goes
out. If necessary, adjust the micro switches.
(Refer to the micro-switch adjustment
procedure)
Maintenance Practices
Page 201
30 Oct 09
