1.

General

This table explains how to troubleshoot the canopy. If you find the trouble in column 1, do the repair
given in column 3.
TROUBLE
Canopy is difficult to move.
Canopy unlock/lock grips
difficult to move.
Emergency side windows
difficult to move.
Canopy warning light does not
operate correctly.
DA201-C1
Rev 16

CANOPY - TROUBLESHOOTING

POSSIBLE CAUSE
Canopy frame damaged.
Latch mechanism out of
adjustment.
Emergency side window guides
dirty or damaged.
Canopy warning light out of
adjustment.
52-10-00
Troubleshooting
REPAIR
Replace the canopy.
Adjust the latch mechanism.
Clean or replace the side
window guides.
Adjust the canopy warning light
micro-switch.
